| Ref | Part Number | Description |
|---|
| 1 |
0437133 |
BEARING KIT This part replaces 0387618. |
| 2 |
0207270 |
MOUNTING TUBE |
| 3 |
0437133 |
BEARING KIT This part replaces 0281011. |
| 4 |
0321223 |
SET SCREW |
| 5 |
0387273 |
STEERING HANDLE ASSY. |
| 6 |
0319596 |
SUPPORT, Ball bearing cup |
| 7 |
0319595 |
CUP, Ball bearing |
| 8 |
0433047 |
BEARING ASSY., Mounting tube This part replaces 0386459. |
| 9 |
0116534 |
STEERING PINION This part replaces 0328229. |
| 10 |
0319523 |
PIN, Pinion to motor tube |
| 11 |
0334697 |
DRIVE, Pinion to direction ind. This part replaces 0319598. |
| 13 |
0328228 |
STEERING GEAR |
| 14 |
0319652 |
SET SCREW, Adj. ring |
| 15 |
0319532 |
PIN, Gear to cable |
| 17 |
0397452 |
CABLE ASSY., Electrical |
| 20 |
0582392 |
SOCKET ASSY., Lamp |
| 21 |
0432936 |
CABLE ASSY., Steering, 5 ft |
| 22 |
0320317 |
ELEEVE,Steering cable |
| 23 |
0283505 |
COVER ASSY., Strg. hsg., Ev. |
| 23 |
0432058 |
COVER ASSY., Strg. hsg., Jo. |
| 24 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 25 |
0319614 |
SCREW, Bar clamp |
| 26 |
0319753 |
BUSHING, Strain relief |
| 27 |
0319653 |
SET SCREW, Steering cable |
| 28 |
0319650 |
TERMINAL BOARD |
| 29 |
0319605 |
GROMMET, Cable lwr mot cov. |
| 30 |
0319777 |
BAR CLAMP, Leads |
| 31 |
0319614 |
SCREW, Bar clamp |
| 32 |
0319614 |
SCREW, Bar clamp |
| 33 |
0329182 |
VIS, borne |
| 34 |
0333440 |
CLAMP, Battery cable |
| 35 |
0327277 |
SCREW, Cover to steering housing |
| 36 |
0305198 |
GASKET, Thermostat |
| 37 |
0333074 |
WASHER, Cable to pedal |
| 38 |
0332338 |
RETAINER, Cable |
| 39 |
0320457 |
LAMP, Direction indicator, 24 V. |
| 40 |
0397450 |
CABLE, Electrical and steering control, 8 ft. |
| 0210943 |
0210943 |
OWNERS MANUAL, Ev. |
| 0283539 |
0283539 |
DECAL SET, Evinrude |
| 0321892 |
0321892 |
SLEEVE Cables, 8 ft. |
| 0397454 |
0397454 |
CABLE, Electrical , 8 ft. |
| 0398861 |
0398861 |
OWNERS MANUAL, Jo. |
| 0432933 |
0432933 |
CABLE ASSY., Steering, 8 ft |
