| Ref | Part Number | Description |
|---|
| 1 |
0433611 |
ELECTRIC MOTOR ASSY., 24v (includes 21, 22 & 24) This part replaces 0392263. |
| 2 |
0333513 |
DRIVE IN, Propeller This part replaces 0326032. |
| 3 |
0319658 |
COTTER PIN, Prop |
| 4 |
0124709 |
PROP., 8 3/4 x 4 weedless This part replaces 0327530. |
| 5 |
0432977 |
ADAPTER & O-RING PKG., 42 in. length This part replaces 0392279. |
| 7 |
0320373 |
BUTT SPLICE |
| 11 |
0321223 |
SET SCREW |
| 12 |
0326969 |
SPACER, Adapter to motor |
| 14 |
0391651 |
TEMPERATURE SWITCH |
| 15 |
0604986 |
SCREW, Switch |
| 16 |
0326968 |
SCREW, Adapter to motor |
| 17 |
0281068 |
MOTOR TUBE & SEAL PKG |
| 17 |
0390494 |
MOTOR TUBE & SEAL PKG. |
| 0327568 |
0433611 |
ELECTRIC MOTOR ASSY., 24v (includes 21, 22 & 24) This part replaces 0327568. |
| 0392264 |
0398259 |
THRU BOLT PACKAGE This part replaces 0392264. |
| 0392266 |
0392266 |
THRUST WASHER PACKAGE |
| 0392267 |
0392267 |
HEAD ASSY., Comm. end, (includes brushes) |
| 0392268 |
0433612 |
HEAD ASSY., Drive end This part replaces 0392268. |
| 0392278 |
0432976 |
ADAPTER & O-RING PKG., 36 in. length This part replaces 0392278. |
| 0392940 |
0392940 |
BRUSH HOLDER & SCREWS |
| 0393170 |
0398545 |
RESISTOR ASSY This part replaces 0393170. |
| 0582407 |
0582407 |
REPLACEMENT BRUSH SET |
