| Ref | Part Number | Description |
|---|
| 1 |
0398908 |
ENGINE COVER ASSY., 225 |
| 1 |
0398909 |
ENGINE COVER ASSY., 200TX |
| 1 |
0398910 |
ENGINE COVER ASSY., 225 |
| 1 |
0398912 |
ENGINE COVER ASSY., 225 |
| 1 |
0431755 |
ENGINE COVER ASSY., 200CX |
| 2 |
0331945 |
BAFFLE |
| 3 |
0331944 |
TILT HANDLE |
| 5 |
0329762 |
LOCATING BRACKET, Front |
| 6 |
0394976 |
LOCATING BRACKET, Rear |
| 8 |
0333579 |
SOUND BLANKET, Side |
| 9 |
0333576 |
SOUND BLANKET, Top |
| 13 |
0331921 |
APPLIQUE, Front |
| 15 |
0331920 |
APPLIQUE, Engine cover, rear |
| 18 |
0332829 |
PLATE, Rear, 225 |
| 18 |
0333177 |
PLATE, Rear, 200TX |
| 18 |
0333471 |
PLATE, Rear, 225 |
| 18 |
0333984 |
PLATE, Rear, 200TX |
| 19 |
0332830 |
PLATE, Applique, front 225 |
| 19 |
0333147 |
PLATE, Applique, front, 225 |
| 19 |
0333472 |
PLATE, Applique, front, 225 |
| 19 |
0333983 |
PLATE, Applique, front, 200CX |
| 20 |
0333577 |
SOUND BLANKET Front |
| 21 |
0333578 |
SOUND BLANKET, Rear |
| 22 |
0397515 |
DECAL SET, 200TX |
| 22 |
0397520 |
DECAL SET, 225 |
| 23 |
0431721 |
OWNER'S MANUAL |
| 23 |
0431813 |
OWNERS MANUAL |
