| Ref | Part Number | Description |
|---|
| 1 |
0122052 |
LOCKWASHER, Solenoid |
| 2 |
0123032 |
DECAL |
| 3 |
0122281 |
NUT, Starting switch |
| 8 |
0305756 |
SCREW, Clamp to motor |
| 11 |
0328731 |
VIS, câble de verrouillage This part replaces 0307055. |
| 12 |
0114095 |
GROMMET |
| 14 |
0330151 |
CLAMP, Harness to oil tank boss This part replaces 0309846. |
| 16 |
0310498 |
WASHER |
| 17 |
0311217 |
MANCHON, solénoïde |
| 18 |
0330112 |
BRIDE, solénoïde vers démarreur This part replaces 0311218. |
| 19 |
0304847 |
JOINT, boulon de démarreur |
| 21 |
0312288 |
SCREW, Safety switch |
| 23 |
0315092 |
SCREW, Air silencer base |
| 24 |
0317400 |
SCREW, Adjustment |
| 25 |
0333929 |
SUPPORT, bâbord This part replaces 0320012. |
| 27 |
0386056 |
INTERRUPTEUR DE DÉMARRAGE AU POINT MORT |
| 28 |
0393354 |
NUT SPRING & SPACER KIT This part replaces 0316740. |
| 29 |
0393354 |
NUT SPRING & SPACER KIT This part replaces 0316741. |
| 30 |
0393354 |
NUT SPRING & SPACER KIT This part replaces 0316742. |
| 40 |
0387680 |
BOLT This part replaces 0321643. |
| 48 |
0582996 |
CÂBLE DE BATTERIE This part replaces 0173254. |
| 51 |
0316101 |
SCREW, Advance |
| 52 |
0386721 |
CÂBLE, 6GA, démarreur vers solénoïde This part replaces 0388246. |
| 0173346 |
0173964 |
ELECTRIC START KIT This part replaces 0173346. |
| 0386591 |
0586278 |
ENSEMBLE MOTEUR DE DÉMARREUR This part replaces 0386591. |
