| Ref | Part Number | Description |
|---|
| 1 |
3858861 |
Module & Decal Ay This part replaces 3857927. |
| 2 |
0309905 |
SCEW,Cylinder head This part replaces 3855578. |
| 4 |
3854521 |
MODULE, Knock |
| 5 |
0303459 |
ECREW,Exhaust cover,1-1/2"long This part replaces 3852048. |
| 6 |
3850266 |
ANCHOR BLOCK |
| 7 |
3856983 |
BRACKET, Throttle cable |
| 8 |
3857319 |
BRACKET, Module & throttle |
| 9 |
3857486 |
STUD, Throttle body |
| 12 |
3857437 |
CLAMP, Fuel line |
| 13 |
3856951 |
FLAME ARRESTOR |
| 14 |
0910150 |
ELBOW, Pump This part replaces 3854675. |
| 15 |
3857476 |
GASKET, Throttle body |
| 16 |
3856944 |
HOSE, Reservoir to pulse limiter |
| 17 |
3857491 |
ROD END, Link |
| 18 |
3854741 |
LEVER, Throttle |
| 19 |
3857490 |
PIN, Throttle cable |
| 20 |
3854743 |
PIN, Throttle cable |
| 21 |
3854744 |
NUT, Pin |
| 23 |
3856974 |
LINK THROTTLE, Lever |
| 24 |
3857685 |
MANIFOLD, Upper |
| 25 |
0329241 |
RONDELLE This part replaces 3852193. |
| 28 |
3853791 |
CLAMP, Flame arrestor |
| 29 |
3857436 |
FITTING, Pulse limiter |
| 30 |
3853729 |
NUT, Lever to bracket |
| 31 |
3857679 |
NUT, Throttle body |
| 32 |
3857691 |
THROTTLE BODY |
| 33 |
3857696 |
AIR CONTROL VALVE |
| 34 |
3857487 |
SENSOR, Throttle position |
| 35 |
3857693 |
SCREW KIT |
| 37 |
3857186 |
COVER |
| 38 |
3857226 |
GASKET, Cover |
| 39 |
3857480 |
PCV VALVE |
| 40 |
3853398 |
SCREW, Clamp to cylinder head |
| 41 |
3857473 |
SCREW, Upper intake |
| 42 |
3857488 |
TUBE, PCV valve |
| 43 |
3854527 |
SENSOR, Manifold air temperature |
| 44 |
3853562 |
GROMMET, Valve cover |
| 45 |
3856975 |
SPACER, Throttle arm |
| 47 |
3850950 |
ANCHOR, Cable |
| 48 |
0329241 |
RONDELLE This part replaces 3852193. |
| 49 |
0328738 |
LOCKWASHER This part replaces 3852189. |
| 50 |
0941263 |
GROMMET, Bracket |
| 51 |
3852019 |
TRUNNION, S.A.E. Cable |
| 52 |
3853398 |
SCREW, Clamp to cylinder head |
