| Ref | Part Number | Description |
|---|
| 33 |
278000999 |
Wire Seal |
| 99 |
278000992 |
Open Barrel |
| 101 |
278001392 |
Open Barrel Terminal |
| 112 |
278000632 |
Female Terminal |
| 113 |
278001661 |
FEMALE TERMINAL - Call your local BRP dealership |
| 121 |
278002375 |
CONNECTOR_FEMALE 3 CAVITIES - Call your local BRP dealership This part replaces 409207400. |
| 122 |
278000739 |
Male Connector, 4 Circuits |
| 133 |
409207200 |
Female Lock |
| 134 |
278000738 |
Male Lock, 4 Circuits |
| 135 |
278000737 |
MALE LOCK, 6 CIRCUITS - Call your local BRP dealership |
| 138 |
293000052 |
Sealing Cap |
| 196 |
293750002 |
Tie Wrap 142 mm |
| 202 |
278001114 |
Female Terminal |
| 227 |
409004300 |
Male Terminal |
| 231 |
278000217 |
Female Housing, 2 Circuits |
| 232 |
278000281 |
Female Terminal Housing, 3 Circuits |
| 242 |
278000218 |
Wire Seal |
| 420 |
414115200 |
Tie-Rap 180 mm |
| 484 |
415128501 |
Seal |
| 525 |
710000482 |
SHRINK TUBING - Call your local BRP dealership |
| 666 |
710000742 |
Little Fuse, 5 Amperes |
| 668 |
710000744 |
Little Fuse, 10 Amperes |
| 669 |
710000745 |
Little Fuse, 15 Ampere |
| 671 |
710000747 |
Little Fuse, 30 Amperes |
| 675 |
415129856 |
Fuse Box Base Ass´y This part replaces 710000660. |
| 684 |
710000781 |
Fuse Puller |
| 702 |
710000836 |
Female Terminal |
| 703 |
710000837 |
Female Terminal |
| 706 |
710000840 |
Cap |
| 732 |
710000877 |
Female Terminal |
| 734 |
710000879 |
Female Housing, 3 Circuits |
| 735 |
710000880 |
Housing, 3 Circuits |
| 736 |
710000881 |
Seal |
| 737 |
710000882 |
Cap |
| 757 |
278001665 |
Female Terminal |
| 766 |
278002164 |
FEMALE TERMINAL - Call your local BRP dealership |
| 767 |
278002165 |
Bus Bar |
| 769 |
278002165 |
Bus Bar |
| 770 |
710001008 |
Little Fuse, 3 AMP |
| 773 |
710001026 |
Fuse Cover |
| 798 |
278002185 |
Male Housing, 4 Circuits |
| 799 |
278002165 |
Bus Bar |
| 800 |
278002187 |
Female Terminal |
| 976 |
710001540 |
CONNECTOR_MALE 6 CAVITIES - Call your local BRP dealership |
| 995 |
278002165 |
Bus Bar |
| 1006 |
710001588 |
Female Terminal Housing, 48 Circuits |
| 1007 |
710001589 |
Female Terminal |
| 1008 |
710001590 |
Female Terminal |
| 1009 |
710001591 |
Cover, 48 positions |
| 1010 |
710001592 |
Plug |
| 1011 |
710001593 |
Plug |
| 1012 |
278002374 |
FEMALE TERMINAL HOUSING, 2 CIRCUITS - Call your local BRP dealership |
| 1135 |
278002451 |
HOUSING - Call your local BRP dealership |
| 1139 |
278002455 |
Female Terminal |
| 2043 |
278002609 |
DECAL FUSE RELAY - Call your local BRP dealership |
