| Ref | Part Number | Description |
|---|
| 33 |
278000999 |
Wire Seal |
| 34 |
409010100 |
Female Terminal |
| 36 |
409010400 |
Female Terminal Housing, 1 Circuit |
| 41 |
515175232 |
Male Terminal |
| 44 |
515175231 |
Female Terminal |
| 46 |
515175282 |
Female Terminal |
| 54 |
515175495 |
Female Housing, 3 Circuits |
| 62 |
278001014 |
Female Terminal |
| 64 |
710000568 |
Housing |
| 68 |
409209500 |
Female Housing, 2 Circuits |
| 69 |
409209600 |
Female Housing, 3 Circuits |
| 73 |
278001013 |
Wire Seal |
| 99 |
278000992 |
Open Barrel |
| 112 |
278000632 |
Female Terminal |
| 123 |
710001540 |
CONNECTOR_MALE 6 CAVITIES - Call your local BRP dealership This part replaces 278000736. |
| 135 |
278000737 |
MALE LOCK, 6 CIRCUITS - Call your local BRP dealership |
| 138 |
293000052 |
Sealing Cap |
| 191 |
410917200 |
Fuse, 30 Amperes |
| 196 |
293750002 |
Tie Wrap 142 mm |
| 223 |
515175320 |
FEMALE TERMINAL - Call your local BRP dealership |
| 225 |
409202700 |
FEMALE TERMINAL HOUSING, 3 CIRCUITS - Call your local BRP dealership |
| 249 |
Not |
Available As Spare Part - Clip |
| 256 |
219704408 |
Tubing 16 Mm 1000Mm Long |
| 332 |
278001326 |
Fuse Holder Cap |
| 333 |
278001325 |
Fuse Holder |
| 337 |
710000113 |
Female Terminal |
| 354 |
515175654 |
Male Terminal Housing, 2 Circuits |
| 355 |
515175658 |
Female Housing, 2 Circuits |
| 366 |
515175673 |
Male Housing, 6 Circuits |
| 371 |
515175678 |
Male Wedge, 6 Circuits |
| 383 |
515175719 |
FEMALE TERMINAL HOUSING, 11 CIRCUITS - Call your local BRP dealership |
| 388 |
278001750 |
FEMALE TERMINAL - Call your local BRP dealership |
| 391 |
278001751 |
MALE HOUSING, 41 CIRCUITS - Call your local BRP dealership |
| 409 |
515175812 |
Plug |
| 410 |
515175801 |
Female Housing, 24 Circuits |
| 411 |
515175802 |
Retainer Block |
| 412 |
515175803 |
Wire Seal |
| 415 |
515175806 |
Female Terminal |
| 417 |
515175819 |
Female Terminal Housing, 8 Circuits |
| 437 |
515175886 |
SEAL - Call your local BRP dealership |
| 438 |
515175883 |
Latch |
| 439 |
515175884 |
LOCK - Call your local BRP dealership |
| 440 |
515175885 |
COVER - Call your local BRP dealership |
| 456 |
278000805 |
Cushion |
| 498 |
710000399 |
Female Housing |
| 645 |
515176164 |
Male Terminal |
| 666 |
710000742 |
Little Fuse, 5 Amperes |
| 668 |
710000744 |
Little Fuse, 10 Amperes |
| 669 |
710000745 |
Little Fuse, 15 Ampere |
| 670 |
710000746 |
Little Fuse, 20 Amperes |
| 675 |
415129856 |
Fuse Box Base Ass´y This part replaces 710000660. |
| 684 |
710000781 |
Fuse Puller |
| 702 |
710000836 |
Female Terminal |
| 703 |
710000837 |
Female Terminal |
| 732 |
710000877 |
Female Terminal |
| 734 |
710000879 |
Female Housing, 3 Circuits |
| 736 |
710000881 |
Seal |
| 737 |
710000882 |
Cap |
| 764 |
710000992 |
Clip |
| 773 |
710001026 |
Fuse Cover |
| 831 |
710001131 |
Female Terminal |
| 930 |
515176621 |
Wire Seal |
| 956 |
278002307 |
FEMALE TERMINAL - Call your local BRP dealership |
| 967 |
278002172 |
Foam |
| 968 |
515176723 |
RELAY-FUSE DECAL - Call your local BRP dealership |
| 981 |
515176774 |
Relay, 30 AMP |
