| Ref | Part Number | Description |
|---|
| 10 |
293750063 |
Clip Tie-Rap |
| 15 |
250100034 |
Push Nut |
| 20a |
415129349 |
Lens |
| 30a |
515176274 |
Halogen Bulb, 60/55 W, 12 V ( H4 ) |
| 30b |
219800280 |
Rubber Cap Protector |
| 30c |
219800281 |
Spring |
| 40 |
293370013 |
E-Circlip |
| 65 |
710004607 |
RADIO HARNESS - Call your local BRP dealership |
| 75 |
250000287 |
Flange Torx Screw K40 X 16 |
| 85 |
293150230 |
Tuflok Plastic Rivet This part replaces 293150089. |
| 90 |
293750058 |
Tie Rap 2 Pièces pour Bordure |
| 95 |
515175220 |
Wrap_Tie 200 X 4.6 - Call Your Local BRP Dealership |
| 100 |
293750058 |
Tie Rap 2 Pièces pour Bordure |
| 115 |
710004437 |
WOOFER SPEAKER - Call your local BRP dealership |
| 120 |
250000577 |
Torx Truss Screw K40 X 12 |
| 125 |
710004437 |
WOOFER SPEAKER - Call your local BRP dealership |
| 130 |
250000577 |
Torx Truss Screw K40 X 12 |
| 135 |
710004438 |
Mid Speaker |
| 140 |
250000577 |
Torx Truss Screw K40 X 12 |
| 145 |
710004438 |
Mid Speaker |
| 170 |
708400046 |
Cap |
| 185a |
219800039 |
Bulb 12V/10W, Amber |
| 185a |
219800304 |
Flasher Bulb |
| 190 |
250100208 |
Panel Nut M6 X 1.0 This part replaces 250100169. |
| 195 |
250000717 |
Torx Head Screw M6 X 16 |
| 200 |
250200164 |
Flat washer M6 |
| 205a |
219800322 |
Bulb 12V 10W |
| 210 |
250100176 |
Panel Nut M5 X 0.8 |
| 215 |
250000715 |
Torx Truss Screw M5 X 20 |
| 220 |
234052670 |
Stainless Steel Flat Washer M5 |
| 230 |
710008103 |
Passenger Detection Switch This part replaces 710005543. |
| 235 |
250100208 |
Panel Nut M6 X 1.0 This part replaces 250100169. |
| 240 |
234062670 |
Stainless Steel Flat Washer |
| 245 |
250000446 |
Torx Screw M6 X 20, Scotch Grip |
| 250 |
515175220 |
Wrap_Tie 200 X 4.6 - Call Your Local BRP Dealership |
| 260 |
710002899 |
Clip Tie-Rap |
| 305 |
710004608 |
LH Cargo Harness |
| 305 |
710004609 |
RH Cargo Harness |
| 310 |
710004643 |
LH Connector Support |
| 310 |
710004644 |
RH Connector Support |
| 315 |
414115200 |
Tie-Rap 180 mm |
| 320 |
250000720 |
Torx Screw K50 X 16 |
| 330 |
250000720 |
Torx Screw K50 X 16 |
| 340 |
710005084 |
Short Antenna |
| 345 |
708302051 |
Antenna Cap |
| 360 |
708301797 |
Antenna Support |
| 365 |
250100208 |
Panel Nut M6 X 1.0 This part replaces 250100169. |
| 370 |
250000722 |
Torx Screw M6 X 20 |
| 385 |
207582044 |
Hex. Flange Screw M8 X 20, Scotch Grip |
| 390 |
250200111 |
Washer |
| 395 |
710001451 |
License Light |
| 410 |
250000287 |
Flange Torx Screw K40 X 16 |
| 445 |
709402446 |
Wiring Harness Support This part replaces 709401619. |
| 450 |
250000742 |
Torx Screw M5 X 14 |
| 460 |
710004583 |
RH Switch Housing |
| 465 |
250000494 |
Socket Screw, M4 X 16 Scotch Grip |
| 470 |
710004231 |
Braided Sleeve |
| 475 |
710004231 |
Braided Sleeve This part replaces 710004489. |
| 485 |
293750001 |
Tie Wrap 94 mm |
| 490 |
293750074 |
Tie Rap |
| 495 |
709401804 |
Wire Guide |
| 500 |
250000453 |
Torx Cutting Screw, M4 X 10 |
| 505 |
709401054 |
Handle Grip |
| 510 |
250000453 |
Torx Cutting Screw, M4 X 10 |
| 520 |
709401055 |
Throttle Handle Grip |
| 525 |
205042594 |
Socket Screw, M4 X 25 |
| 530 |
234040600 |
Flat Washer 4 mm |
| 540 |
709401801 |
Bushing |
| 545 |
709401937 |
Spring |
| 555 |
293720084 |
Grommet |
| 560a |
415129261 |
Bulb 12V 10W |
| 575 |
219800456 |
Kit Speed Sensor This part replaces 710005712. |
| 580 |
205561660 |
Socket Head Screw M6 X 16, Scotch Grip |
| 585 |
705601512 |
Front Sensor Wheel |
| 590 |
250000995 |
Torx-truss M/s M6 X 10 This part replaces 250000747. |
| 595 |
710004860 |
LH Support Wire |
| 600 |
414115200 |
Tie-Rap 180 mm |
| 605 |
710003156 |
Speed Sensor Holder |
| 610 |
210261250 |
Hex. Flange Screw M6 X 12 |
| 615 |
219800456 |
Kit Speed Sensor This part replaces 710004923. |
| 620 |
205561660 |
Socket Head Screw M6 X 16, Scotch Grip |
| 625 |
705601512 |
Front Sensor Wheel |
| 630 |
250000995 |
Torx-truss M/s M6 X 10 This part replaces 250000747. |
| 635 |
710004861 |
RH Support Wire |
| 640 |
414115200 |
Tie-Rap 180 mm |
| 645 |
710003157 |
Speed Sensor Holder |
| 650 |
210261250 |
Hex. Flange Screw M6 X 12 |
| 655 |
706202361 |
Speed Sensor |
| 660 |
205561660 |
Socket Head Screw M6 X 16, Scotch Grip |
| 665 |
293750001 |
Tie Wrap 94 mm |
| 670 |
710002023 |
Shim |
| 680 |
705601372 |
Sensor Wheel |
