| Ref | Part Number | Description |
|---|
| 10 |
520002715 |
Snow Guard |
| 400 |
520001900 |
Red, RH Rear Reflector |
| 410 |
520001901 |
Red, LH Rear Reflector |
| 1000 |
520002343 |
RH Front Reflector |
| 1010 |
520002344 |
LH Front Reflector |
| 2010 |
520003222 |
Snow Guard Reinforcement |
| 5000aa |
250000757 |
Button Head Torx Screw M8 X 25 S.Gr |
| 5000ab |
234082670 |
Stainless Steel Flat Washer |
| 5000ac |
250200128 |
Flat Washer 8 mm |
| 5000ad |
233281466 |
Elastic Flange Nut M8 |
| 5000af |
293150292 |
Black, Pop Rivet 3/16 X ,550 |
| 5000ag |
517124300 |
Washer |
| 5000aj |
860200164 |
Grip Plate Kit |
| 5000v10 |
293150308 |
Black, Ornit Rivet 3/16 X ,675 This part replaces 293150308. |
| 5000v11 |
517124300 |
Washer |
| 5000v12 |
293150306 |
Black, Ornit Rivet 3/16 X ,800 |
| 5000v13 |
293150291 |
Black, Pop Rivet 3/16 X ,425 |
| 5000w |
520001499 |
Wrench |
| 5000x |
417127579 |
Belt Installation Tool |
| 5000y |
520003221 |
Washer |
| 5000z |
503192360 |
Stopper Strap |
