| Ref | Part Number | Description |
|---|
| CRD |
409012100 |
Female Terminal |
| CRD |
409012300 |
Seal |
| CRD |
409209200 |
Female Terminal Housing, 2 Circuits |
| CRG |
409012100 |
Female Terminal |
| CRG |
409012300 |
Seal |
| CRG |
409209200 |
Female Terminal Housing, 2 Circuits |
| DC5A |
278001008 |
Insulated Sheath |
| DC5A |
278002261 |
Female Terminal |
| DC5B |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| DC5B |
278001007 |
Insulated Sheath |
| DC5B |
710000421 |
Female Terminal |
| HIC5 |
278000223 |
Female Terminal |
| HIC5 |
278000395 |
Male Housing, 4 Circuits |
| HIC5 |
278001065 |
Wire Seal This part replaces 278000585. |
| HIC6 |
278000223 |
Female Terminal |
| HIC6 |
278000273 |
Male Housing, 3 Circuits |
| HIC6 |
278001065 |
Wire Seal This part replaces 278000585. |
| HIC7 |
278000218 |
Wire Seal |
| HIC7 |
278000220 |
Male Connector, 2 Circuits |
| HIC7 |
409007300 |
Female Terminal |
| PRD |
278000998 |
Female Terminal |
| PRD |
415128501 |
Seal |
| PRD |
710002104 |
Housing |
| PRG |
278000998 |
Female Terminal |
| PRG |
415128501 |
Seal |
| PRG |
710002104 |
Housing |
| TG |
278000217 |
Female Housing, 2 Circuits |
| TG |
278001065 |
Wire Seal This part replaces 278000585. |
| TG |
710002249 |
CLIP - Call your local BRP dealership |
| 32 |
278000998 |
Female Terminal |
| 226 |
278000222 |
Male Terminal |
| 228 |
409007300 |
Female Terminal |
| 229 |
278000223 |
Female Terminal |
| 231 |
278000217 |
Female Housing, 2 Circuits |
| 237 |
278000220 |
Male Connector, 2 Circuits |
| 238 |
278000273 |
Male Housing, 3 Circuits |
| 239 |
278000395 |
Male Housing, 4 Circuits |
| 242 |
278000218 |
Wire Seal |
| 253 |
219704425 |
Tubing 6 Mm 3000Mm Long |
| 254 |
219704399 |
Was 409901700 Tubing (9 mm) |
| 280 |
409012100 |
Female Terminal |
| 283 |
409209200 |
Female Terminal Housing, 2 Circuits |
| 284 |
409012300 |
Seal |
| 295 |
278001008 |
Insulated Sheath |
| 297 |
278001007 |
Insulated Sheath |
| 387 |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| 484 |
415128501 |
Seal |
| 504 |
278001065 |
Wire Seal This part replaces 278000585. |
| 506 |
710000421 |
Female Terminal |
| 765 |
293740027 |
Adhesive Tape |
| 918 |
278002261 |
Female Terminal |
| 1160 |
710002104 |
Housing |
| 1176 |
710002249 |
CLIP - Call your local BRP dealership |
| 1302 |
710002711 |
Shrink Tubing |
