Parts Catalog

07- Front Suspension And Ski - Commander - 800R E-TEC

Parts (54)

Ref	Part Number	Description
1	505074262	Black, Ski Blade Xc
3	860202821	Round Carbide Runner Kit This part replaces 860200959.
4	233201414	Hex. Flanged Elastic Nut M10
5	505073651	Orange, Handle
6	505071812	Retainer 17mm long
7	505072133	Retainer 23mm Long
8	250000703	Hex. Screw M10 X 130
9	506133300	Spacer
10	503192496	Washer
11	233201464	Hex. Elast. Flanged Nut M10 x 1.5
12	505072594	Ski Stopper
13	505073579	Black LH Ski Leg
13	505073580	Black RH Ski Leg
14	505072690	Leg Bushing
15	505072807	Spacer
16	505073924	LH Arm-lower
16	505073925	RH Arm-lower
17	505073330	Bushing
18	505072209	Bushing
19	505072634	Wear Plate
20	250001024	Screw Hex. M10 X 70
21	505073985	LH Arm-upper W Sway Bar
21	505073986	RH Arm-upper W Sway Bar
22	505073329	Bushing
23	505072143	Bushing
24	250001023	Screw Hex. M10 X 60 This part replaces 250000290.
25	250001022	Screw Hex. M10 X 50 This part replaces 250000289.
26	503189564	Washer
27	505072392	Washer
28	250100165	Hex. Flanged Elastic Nut M10
29	505072444	Stabilisator
31	505072445	Bushing
32	505074294	Stabilisator Lever
33	207663046	Hex. Flange Screw M6 X 30
34	233261416	Elastic Flanged Nut M6 X 1.0
35	505074123	Double Ball Joint Link
36	505073962	Anti Roll Bar Link, Rh
37	207663046	Hex. Flange Screw M6 X 30
38	233261416	Elastic Flanged Nut M6 X 1.0
46	505074410	Front Shock
47	505072846	Deep Black Spring
48	503194270	Spring Stopper
49	505072753	Adjustment Knob
50	250000644	Allen Screw M3 X 0.5 X 10 This part replaces 205031060.
51	207005544	Hex. Screw M10 X 55
52	207006544	Hex. Screw M10 X 1.5 X 65
53	503189564	Washer
54	233201414	Hex. Flanged Elastic Nut M10
55	505073636	Ball Joint
56	293370070	Circlip
57	234021410	Flat Washer 12 mm
58	250100089	Hex. Elastic Hex. Nut M12
59	505072913	Upper Ball Joint
60	293370035	Circlip
