| Ref | Part Number | Description |
|---|
| 17 |
0305123 |
O RING |
| 26 |
0434467 |
NEEDLE BEARING ASSY. |
| 36 |
0329864 |
SHIFT ROD |
| 36 |
0329865 |
SHIFT ROD |
| 37 |
5004590 |
Gearset Ay This part replaces 0434064. |
| 53 |
5007671 |
DRIVESHAFT Assembly, Upper This part replaces 0337058. |
| 53 |
5007672 |
DRIVESHAFT Assembly, Upper This part replaces 0337059. |
| 55 |
0335684 |
DRIVESHAFT SPRING |
| 60 |
0338743 |
TRIM TAB This part replaces 0333961. |
| 62 |
0335221 |
SCREW, Throttle body to reed plate This part replaces 0328715. |
| 63 |
0435027 |
CUP & PLATE This part replaces 0330379. |
| 63 |
0435526 |
CHROME CUP & PLATE KIT This part replaces 0330384. |
| 65 |
0313715 |
SCREW, Cap, hex hd, 7/16-14 x 1 |
| 66 |
0435027 |
CUP & PLATE This part replaces 0330380. |
| 66 |
0435526 |
CHROME CUP & PLATE KIT This part replaces 0330383. |
| 70 |
0331998 |
SCREW, Gearcase to housing |
| 72 |
0331999 |
SCREW, Gearcase housing |
| 73 |
0331353 |
Seal, Impeller Housing Plate. |
| 80 |
0330263 |
SCREW, Mounting, 3/8 in. X 3.50 in. |
| 81 |
0332000 |
SEAL RING |
| 83 |
0435485 |
IMPELLER HOUSING ASSY. This part replaces 0395040. |
| 85 |
0174927 |
PROPELLER, 15 x 15 SST |
| 85 |
0390821 |
PROPELLER, 14 1/2 x 19 SST II |
| 85 |
0390822 |
PROPELLER 14-1/4 X 21 |
| 85 |
0390823 |
PROPELLER 14-1/4 X 23 |
| 85 |
0394214 |
LH SRX 14 1/2 x 27 |
| 85 |
0394215 |
PROPELLER, 14 1/2 X 29 OMC RAKER |
| 85 |
0398502 |
PROPELLER, 14 1/2 X 20 RACKER |
| 85 |
0398503 |
LH Raker 14 1/2 x 22 |
| 85 |
0398504 |
LH Raker 14 1/2 x 24 |
| 85 |
0398505 |
LH Raker 14 1/2 x 26 |
| 85 |
0398506 |
LH Raker 14 1/2 x 28 |
| 85 |
0431930 |
PROPELLER, 15 x 17 SSS II |
| 88 |
5006373 |
GEARCASE SEAL KIT This part replaces 0434516. |
| 89 |
5001594 |
WATER PUMP REPAIR KIT This part replaces 0395060. |
| 0433632 |
5000776 |
Kit Ay This part replaces 0433632. |
| 0434013 |
5000775 |
Kit Ayd/Shaft-20 This part replaces 0434013. |
| 0435302 |
5009324 |
Gcase/Coro/Wht/Os This part replaces 0435302. |
| 0435303 |
0435303 |
GEARCASE, ASSY., Complete |
