| Ref | Part Number | Description |
|---|
| 500a |
705019189 |
Tank Trim |
| 501 |
705015250 |
Self-Adhesive Spacer |
| 510 |
234062670 |
Stainless Steel Flat Washer |
| 520 |
250000705 |
Torx Truss Screw M6 X 20 |
| 600a1 |
705007790 |
Bare, LH Lower Console Fairing |
| 600b |
705009153 |
Acoustic Foam |
| 600c |
250000958 |
Panel Nut M5 X 0.8 |
| 610 |
705010890 |
Spacer |
| 620 |
293150230 |
Tuflok Plastic Rivet |
| 700a1 |
705007791 |
Bare, RH Lower Console Fairing |
| 700b |
705009154 |
Acoustic Foam |
| 700c |
250000958 |
Panel Nut M5 X 0.8 |
| 710 |
705010890 |
Spacer |
| 720 |
293150230 |
Tuflok Plastic Rivet |
| 800a1 |
705010851 |
Bare, LH Fairing |
| 800b |
705009155 |
Acoustic Foam |
| 800c |
705009157 |
Acoustic Foam |
| 800d |
705009159 |
Acoustic Foam |
| 800f |
705006634 |
Polyurethane Stopper |
| 800g |
219704373 |
Seal 1000Mm Long |
| 800h |
705020348 |
Deep Black, LH Scoop |
| 800j |
705009430 |
Anchor Pin |
| 800k |
250001131 |
Torx Truss PT K40 x 12 |
| 800m |
704905126 |
Matt Black, Logo Can-Am |
| 800n |
705017994 |
LH Fascia Grille |
| 800p |
250000720 |
Torx Screw K50 X 16 |
| 810 |
293150230 |
Tuflok Plastic Rivet |
| 820 |
250000726 |
Torx-Truss M/S Nylon Patch M5X26 |
| 825 |
234052670 |
Stainless Steel Flat Washer M5 |
| 900a1 |
705010835 |
Bare. RH Fairing |
| 900b |
705009156 |
Acoustic Foam |
| 900c |
705009158 |
Acoustic Foam |
| 900d |
705009160 |
Acoustic Foam |
| 900f |
705006634 |
Polyurethane Stopper |
| 900g |
219704373 |
Seal 1000Mm Long |
| 900h |
705020349 |
Deep Black, RH Scoop |
| 900j |
705009430 |
Anchor Pin |
| 900k |
250001131 |
Torx Truss PT K40 x 12 |
| 900m |
704905126 |
Matt Black, Logo Can-Am |
| 900n |
705017995 |
RH Fascia Grille |
| 900p |
250000720 |
Torx Screw K50 X 16 |
| 910 |
293150230 |
Tuflok Plastic Rivet |
| 920 |
250000726 |
Torx-Truss M/S Nylon Patch M5X26 |
| 925 |
234052670 |
Stainless Steel Flat Washer M5 |
| 1500a |
705020287 |
Acoustic Panel |
| 1500b |
705009344 |
Acoustic Foam |
| 1500c |
705009162 |
Acoustic Foam |
| 1500d |
708000759 |
Rubber Stopper |
| 1500f |
705007780 |
LH Engine Fairing |
| 1500g |
250000725 |
Screw M4 X 16 |
| 1510 |
205562060 |
Socket Head Screw M6 X 20, Scotch Grip |
| 1515 |
234061600 |
Stainless Flat Washer M6 |
| 1520 |
293730024 |
Dart, Fastex |
| 1600 |
705007781 |
RH Engine Fairing |
| 1610 |
205562060 |
Socket Head Screw M6 X 20, Scotch Grip |
