| Ref | Part Number | Description |
|---|
| 1 |
512047000 |
Sender temperature |
| 2 |
509000187 |
Pressure Cap This part replaces 414684700. |
| 3 |
5242425 |
Radiator |
| 4 |
414989800 |
BLEEDER SCREW - Call your local BRP dealership |
| 5 |
27003 |
Hose clamp |
| 7 |
509000046 |
ENGINE OUTLET HOSE - Call your local BRP dealership |
| 8 |
5441471 |
Hose |
| 9 |
509000219 |
T-Fitting This part replaces 414619900. |
| 10 |
Not |
Available As Spare Part - Hose - DOES NOT APPLY TO THIS MODEL |
| 11 |
Not |
Available As Spare Part - Hose - DOES NOT APPLY TO THIS MODEL |
| 12 |
Not |
Available As Spare Part - Hose - DOES NOT APPLY TO THIS MODEL |
| 13 |
5441703 |
Hose plug |
| 14 |
39038 |
Overflow hose 9.5/6.5 |
| 15 |
413702300 |
SEALANT-TEFLON - Call your local BRP dealership |
| 16 |
36083 |
Rivet |
| 17 |
36489 |
Rivet TSPD68 4.8x12 (1 PAC <=> 50 PC) - Call your local BRP dealership |
| 18 |
Not |
Available As Spare Part - Cover hose - DOES NOT APPLY TO THIS MODEL |
| 19 |
Not |
Available As Spare Part - Coolant/oil-tank - DOES NOT APPLY TO THIS MODEL |
| 20 |
5445102 |
Cover hose |
| 21 |
5445103 |
Hose |
| 22 |
414684600 |
Neck-filler |
| 23 |
5346017 |
Hose |
| 24 |
5346018 |
Hose |
| 25 |
40030 |
Screw M6x20 |
| 26 |
20003 |
Washer |
