| Ref | Part Number | Description |
|---|
| 10a11 |
518335959 |
Front Suspension Arm Reinforcement This part replaces 518329659. |
| 10a12 |
518333792 |
RH Rear Suspension Support |
| 10a13 |
518333791 |
LH Rear Suspension Support |
| 10a14 |
518329789 |
RH Footrest Reinforcement |
| 10a15 |
518332924 |
Deep Black, LH Chassis Reinforcement |
| 10a16 |
518329648 |
RH Roller |
| 10a17 |
518328452 |
LH Roller |
| 10a18 |
518334842 |
Central Rear Tunnel Reinforcement |
| 10a19 |
518334843 |
LH Central Reinforcement Tunnel |
| 10a21 |
518335119 |
Radiator Tunnel 154 |
| 10a22 |
250300652 |
Protruding Stud M8 x 22 |
| 10a23 |
250100199 |
Insert Half Hex Body M6 x 1.0 |
| 10a26 |
518332315 |
Rear Cap |
| 10a27 |
250001151 |
Torx Button Head Screw M8 X 25 |
| 10a29 |
518331822 |
RH Footrest |
| 10a3 |
518332803 |
Deep Black, RH Footrest Reinforcement |
| 10a30 |
293730052 |
Black, Plug |
| 10a31 |
518332978 |
LH Footrest |
| 10a33 |
293150203 |
Rivet Avibulb 3/16 |
| 10a34 |
293150237 |
Avibulb Rivet 4.8 X 12.1 |
| 10a36 |
293150245 |
Henrob Rivet |
| 10a38 |
293150264 |
Rivet Ornit 6,5 X 10.5 |
| 10a39 |
293150265 |
Rivet Ornit 6,5 X 12.5 |
| 10a41 |
293150266 |
Ornit Rivet 6,5 X 14.5 |
| 10a6 |
518332802 |
Deep Black, LH Footrest Reinforcement |
| 10a7 |
518329368 |
LH Frame Corner 20 |
| 10a8 |
518329369 |
RH Molded Spacer |
| 20 |
293730052 |
Black, Plug |
| 35 |
518331727 |
RH Stirrup Reinforcement |
| 40 |
293450275 |
Insert |
| 42 |
250000717 |
Torx Head Screw M6 X 16 |
| 95 |
293450275 |
Insert |
| 96 |
293450275 |
Insert |
| 170 |
293450267 |
Insert M5 - 0.8 |
| 200 |
518332541 |
Lateral Reinforcement |
| 205 |
207682044 |
Hex. Flange Screw M8 X 20 |
| 210 |
232081414 |
Hex. Nut M8 |
| 230 |
207562056 |
Hex. Flange Screw M6 X 20 |
| 425 |
207562056 |
Hex. Flange Screw M6 X 20 |
| 430 |
233261416 |
Elastic Flange Nut M6 X 1.0 |
| 860 |
518335168 |
Deep Black, LH Rear Footrest Reinforcement |
| 865 |
518335169 |
Deep Black, RH Rear Footrest Reinforcement |
| 875 |
293150267 |
Rivet Ornit 6,5 X 16.5 |
| 880 |
293150148 |
Rivet Magna-Grip 6,4 X 50,8 |
| 885 |
293150149 |
Collar Huck Magna-Grip 6.4 |
| 1400 |
293730047 |
Black, Dart 8 mm |
| 1405 |
293730060 |
Black, Dart 10 mm |
| 1700 |
518329982 |
Front Protector |
| 1710 |
293150308 |
Black, Ornit Rivet 3/16 X ,675 This part replaces 293150308. |
| 3040 |
293730079 |
Dart |
| 3050 |
293150154 |
Magna-Grip Rivet 6.4 X 65,9 |
