09- Decals
Parts (11)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 5447014 | Pulley decal |
| 2 | 5447012 | Oil check decal |
| 3 | 5347660 | Control panel decal |
| 4 | 5348181 | Instruction decal |
| 5 | 516008738 | Logo 48mm "BRP" This part replaces 219902468. |
| 6 | 5447929 | Instruction decal |
| 7 | 516001721 | L.H. Console decal |
| 8 | 605448799 | PULLING BAR DECAL - Call your local BRP dealership |
| 9 | 605448801 | Warning label |
| 10 | 605354320 | R.H. Hood decal, upper |
| 10 | 605354321 | L.H. Hood decal, upper |
