| Ref | Part Number | Description |
|---|
| 1 |
605156016 |
LUGGAGE RACK - Call your local BRP dealership |
| 2 |
40316 |
Hex Sc. M8 x 20 BN73 m(1=10pcs) - Call your local BRP dealership |
| 3 |
515175397 |
LAMP HOUSING - Call your local BRP dealership |
| 4 |
40207 |
Plate Screw Zn 4.8x45 DIN 7981(1=10pcs) - Call your local BRP dealership |
| 5 |
520000758 |
Bulp |
| 6 |
414513700 |
Lens |
| 7 |
414516400 |
Washer - Call your local BRP dealership |
| 8 |
209632540 |
Screw |
| 9 |
515175852 |
Wire ass'y |
| 10 |
42269 |
Connector housing |
| 11 |
605642628 |
CONNECTOR - Call your local BRP dealership |
| 13 |
Not |
Available As Spare Part - Hitch |
| 14 |
5440767 |
Lock |
| 15 |
41012 |
Pin |
| 16 |
41029 |
Hair pin |
| 17 |
545693 |
SPRING - Call your local BRP dealership |
| 18 |
605448799 |
PULLING BAR DECAL - Call your local BRP dealership |
| 19 |
5447929 |
Instruction label |
| 20 |
232581414 |
Hex. Elastic Stop Nut M8 This part replaces 33011. |
| 21 |
234081410 |
Flat Washer 8 mm This part replaces 20004. |
| 22 |
40009 |
Hex. screw M8 x 50 |
| 23 |
605251392 |
MOLD TAIL LAMP - Call your local BRP dealership |
| 24 |
40206 |
Plate Screw Zn 4.8x25 DIN 7981(1=10pcs) - Call your local BRP dealership |
| 25 |
605251963 |
BASE - Call your local BRP dealership |
| 26 |
40322 |
SELF TAPPING SCREW M6 X 16 - Call your local BRP dealership |
| 27 |
516008738 |
Logo 48mm "BRP" This part replaces 219902468. |
