| Ref | Part Number | Description |
|---|
| 1 |
3852217 |
COIL ASSY. Ignition This part replaces 0383444. |
| 2 |
0912878 |
BRACKET, Ignition leads |
| 3 |
3852491 |
RETAINER, 4 Wire This part replaces 0910230. |
| 4 |
3852492 |
RETAINER, 3 wire This part replaces 0910231. |
| 5 |
0984997 |
LEAD ASSY., Distributor to coil |
| 5 |
3853826 |
LEAD ASSY., Cylinder #2 This part replaces 0984675. |
| 6 |
0984990 |
LEAD ASSY., Cylinder #8 |
| 6 |
0984992 |
LEAD ASSY., Cylinder #6 |
| 6 |
0984993 |
LEAD ASSY., Cylinder #5 |
| 6 |
0984994 |
LEAD ASSY., Cylinder #1 |
| 6 |
0984996 |
LEAD ASSY., #2 |
| 6 |
3853819 |
LEAD ASSY., Cylinder #7 This part replaces 0984538. |
| 6 |
3853820 |
LEAD ASSY., Cylinder #3 & 6 This part replaces 0984539. |
| 6 |
3853821 |
LEAD ASSY., Cylinders 5 & 6 This part replaces 0984545. |
| 6 |
3853822 |
LEAD ASSY., Cylinders #1 & 5 This part replaces 0984546. |
| 6 |
3853823 |
LEAD ASSY., Cylinders #4 & 8 This part replaces 0984616. |
| 6 |
3853824 |
Lead Ay This part replaces 0984617. |
| 6 |
3853826 |
LEAD ASSY., Cylinder #2 This part replaces 0984675. |
| 6 |
3853831 |
LEAD, Distributor to #3 & 4 This part replaces 0984991. |
| 6 |
3853832 |
LEAD, Distributor to #5 & 6 This part replaces 0984995. |
| 7 |
3852619 |
RETAINER This part replaces 0912850. |
| 10 |
0306519 |
SCR,Coil clamp |
| 12 |
0120177 |
L'WASHER, Alternator to brkt |
| 13 |
0306834 |
BOLT, Throttle lever retainer |
| 14 |
3852218 |
BRACKET, Oil cooler This part replaces 0383448. |
| 20 |
515178492 |
Braided Sleeve 60MM Long |
| 300 |
512061696 |
LH Machined Brace This part replaces 512061447. |
| 310 |
512061449 |
Upper CVT Cooling Duct |
| 315 |
250000995 |
Torx-truss M/s M6 X 10 |
| 317 |
207563544 |
Screw H Flange S.Grip M6 X 35 |
| 320 |
512061450 |
Lower CVT Cooling Duct |
| 325 |
250000995 |
Torx-truss M/s M6 X 10 |
| 420 |
293370122 |
Circlip |
| 440 |
207551044 |
Hex. Flange Screw M5 X 10 |
| 1000 |
512061689 |
LH Rear Engine Support Ass'y This part replaces 512061416. |
| 1020 |
250001016 |
Hex Flanged Screw M8 X 25 S.Grip |
| 1030 |
250200146 |
Conical Spring Washer M8 |
| 1200 |
512061418 |
LH Front Engine Support Ass'y |
| 1210 |
250001016 |
Hex Flanged Screw M8 X 25 S.Grip |
| 1220 |
250200146 |
Conical Spring Washer M8 |
| 1300 |
512061439 |
RH Front Engine Support |
| 1305 |
512061454 |
Vibration Damper |
| 1310 |
250001016 |
Hex Flanged Screw M8 X 25 S.Grip |
| 1320 |
250200146 |
Conical Spring Washer M8 |
| 1330 |
250001062 |
Hex. Flanged Screw M6 X 16 |
| 1400 |
512061411 |
RH Rear Engine Support Ass'y |
| 1410 |
250001016 |
Hex Flanged Screw M8 X 25 S.Grip |
| 1420 |
250200146 |
Conical Spring Washer M8 |
| 1500 |
512061454 |
Vibration Damper |
| 1540 |
250001062 |
Hex. Flanged Screw M6 X 16 |
| 1550 |
207585544 |
Hex. Flange Screw M8 X 55 |
| 1560 |
503183200 |
Yellow, Washer |
| 1570 |
250200008 |
Flat Washer With Teflon 8 mm |
| 1580 |
205082544 |
Socket Screw M6 X 20, Scotch Grip |
| 1585 |
503183200 |
Yellow, Washer |
| 1595 |
232581414 |
Hex. Elastic Stop Nut M8 |
| 1700 |
512061530 |
Engine Stopper |
| 2000d |
732610072 |
Push Nut |
| 2000f |
512061083 |
Rubber |
| 2000g |
420441840 |
Distance Screw |
| 2010 |
512061325 |
Cable Guide |
| 2020 |
250000759 |
Torx Truss Pt K40 X 16 |
| 2030 |
293650212 |
GEMI Clamp |
| 2050 |
420201630 |
Rubber Cap |
| 2060 |
512061274 |
Airbox Support |
| 2070 |
293150103 |
Pop Rivet 3/16 |
| 2080 |
293150104 |
Pop Rivet 3/16 |
| 3600 |
512061224 |
Throttle Cable |
| 3690 |
414274500 |
Circlip |
| 3800 |
512060859 |
Upper Housing Ass'y |
| 3810 |
512060860 |
Lower Housing |
| 3820 |
512061544 |
Heated Hand Lever Accelerator |
| 3840 |
250000991 |
Flanged Screw M5x12 |
| 4200 |
512061168 |
Ignition Coil |
| 4210 |
243141630 |
Hex. Plastic Screw M4.8 X 16 |
| 4220 |
512061166 |
Ignition Cable |
| 4240 |
512061238 |
Spark Plug Wire Holder |
| 4270 |
293300059 |
O-Ring |
| 5050 |
512060993 |
Clamp |
| 5300 |
512060136 |
Starter Grip (Optional) |
