| Ref | Part Number | Description |
|---|
| BM |
278000992 |
Open Barrel |
| BP |
515177174 |
Terminal |
| CM |
409209600 |
Female Housing, 3 Circuits |
| CM |
515176621 |
Wire Seal |
| CM |
710001340 |
Female Terminal |
| COM |
278000632 |
Female Terminal |
| COM |
293000052 |
Sealing Cap |
| COM |
515175673 |
Male Housing, 6 Circuits |
| COM |
515175678 |
Male Wedge, 6 Circuits |
| CV |
515175801 |
Female Housing, 24 Circuits |
| CV |
515175802 |
Retainer Block |
| CV |
515175803 |
Wire Seal |
| CV |
515175806 |
Female Terminal |
| CV |
515175812 |
Plug |
| CV |
710000399 |
Female Housing |
| CV |
710001131 |
Female Terminal |
| DB |
278001751 |
MALE HOUSING, 41 CIRCUITS - Call your local BRP dealership |
| DB |
515175883 |
Latch |
| DB |
515175884 |
LOCK - Call your local BRP dealership |
| DB |
515175885 |
COVER - Call your local BRP dealership |
| DB |
515175886 |
SEAL - Call your local BRP dealership |
| DB |
515177481 |
FEMALE TERMINAL - Call your local BRP dealership |
| DS |
515175231 |
Female Terminal |
| DS |
515175495 |
Female Housing, 3 Circuits |
| FA |
278000805 |
Cushion |
| FA |
278001325 |
Fuse Holder |
| FA |
278001326 |
Fuse Holder Cap |
| FA |
410917200 |
Fuse, 30 Amperes |
| FA |
710000113 |
Female Terminal |
| FB |
278000999 |
Wire Seal |
| FB |
415128501 |
Seal |
| FB |
415129856 |
Fuse Box Base Ass´y This part replaces 710000660. |
| FB |
515176774 |
Relay, 30 AMP |
| FB |
515177009 |
Female Terminal |
| FB |
710000742 |
Little Fuse, 5 Amperes |
| FB |
710000744 |
Little Fuse, 10 Amperes |
| FB |
710000745 |
Little Fuse, 15 Ampere |
| FB |
710000746 |
Little Fuse, 20 Amperes |
| FB |
710000781 |
Fuse Puller |
| FB |
710000840 |
Cap |
| FB_C |
278002172 |
Foam |
| FB_C |
516005571 |
RELAY FUSE DECAL - Call your local BRP dealership |
| FB_C |
710000742 |
Little Fuse, 5 Amperes |
| FB_C |
710000744 |
Little Fuse, 10 Amperes |
| FB_C |
710000745 |
Little Fuse, 15 Ampere |
| FB_C |
710000746 |
Little Fuse, 20 Amperes |
| FB_C |
710001026 |
Fuse Cover |
| HG |
515175231 |
Female Terminal |
| HG |
515175282 |
Female Terminal |
| HG |
515175349 |
FEMALE TERMINAL HOUSING, 13 CIRCUITS - Call your local BRP dealership |
| HIC |
278000632 |
Female Terminal |
| HIC |
278000737 |
MALE LOCK, 6 CIRCUITS - Call your local BRP dealership |
| HIC |
293000052 |
Sealing Cap |
| HIC |
710001540 |
CONNECTOR_MALE 6 CAVITIES - Call your local BRP dealership This part replaces 278000736. |
| IR |
515175231 |
Female Terminal |
| IR |
515175658 |
Female Housing, 2 Circuits |
| NV |
515176164 |
Male Terminal |
| NV |
515176621 |
Wire Seal |
| NV |
710000568 |
Housing |
| NV |
710000992 |
Clip |
| PA |
515176908 |
Female Housing |
| PA |
515176909 |
Terminal |
| PB |
515176908 |
Female Housing |
| PB |
515176909 |
Terminal |
| PE |
278001481 |
Female Terminal |
| PE |
278001482 |
Seal |
| PE |
710001132 |
Housing |
| PE |
710001133 |
Lock |
| RE |
710000877 |
Female Terminal |
| RE |
710000879 |
Female Housing, 3 Circuits |
| RE |
710000881 |
Seal |
| RE |
710000882 |
Cap |
| SA |
515175231 |
Female Terminal |
| SA |
515175495 |
Female Housing, 3 Circuits |
| SB |
515176164 |
Male Terminal |
| SB |
515176621 |
Wire Seal |
| SB |
710000568 |
Housing |
| SC |
515175919 |
Protector Cap |
| SC |
710000506 |
Open Barell |
| SD |
409010100 |
Female Terminal |
| SD |
409010400 |
Female Terminal Housing, 1 Circuit |
| VC |
515175231 |
Female Terminal |
| 420 |
414115200 |
Tie-Rap 180 mm |
| 775 |
293730040 |
Mount Dart |
