| Ref | Part Number | Description |
|---|
| 2 |
0301967 |
O RING |
| 5 |
0318626 |
BILLE |
| 6 |
0391849 |
ROULEMENT À BILLES |
| 13 |
0912041 |
BEARING |
| 31 |
0306503 |
SCREW, Short |
| 32 |
0309484 |
SCREW |
| 38 |
0325115 |
SCREW, Oil tank/EMM mount |
| 51 |
0984919 |
HOSE, Valve housing to engine cover |
| 54 |
0317000 |
COLLIER, câble |
| 55 |
0985529 |
CLAMP AND GROMMET KIT This part replaces 0912296. |
| 58 |
0912112 |
RETAINING RING |
| 61 |
0985055 |
SHAFT |
| 63 |
0984372 |
BEARING, Lower |
| 64 |
0304612 |
RETAINING RING |
| 65 |
0912463 |
SPACER |
| 71 |
0912152 |
HOSE, Control valve to adapter |
| 72 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 74 |
0330366 |
HOSE, Control valve to cover |
| 77 |
0912064 |
SLEEVE, Oil cooler |
| 78 |
0912000 |
ELBOW, Oil cooler |
| 81 |
0912329 |
SLEEVE, Return tube |
| 82 |
0984190 |
TUBE ASSY., Engine cover to oil cooler |
| 83 |
0912226 |
GROMMET, Return tube |
| 84 |
0331887 |
HOSE, Overboard |
| 0984216 |
0984216 |
STEERING PUMP KIT |
