07- Body - Warning Decals
Parts (24)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 5033691 | BODY Assy, THROTTLE |
| 3 | 5031642 | BOLT |
| 4 | 5033693 | ROD, THROTTLE |
| 6 | 5033781 | HOLDER |
| 7 | 5033782 | LEVER, THROTTLE #1 |
| 8 | 5037178 | ROD This part replaces 5033783. |
| 9 | 5030760 | CONNECTEUR, TRINGLERIE D’ACCÉLÉRATEUR |
| 10 | 5033784 | LEVER, THROTTLE |
| 11 | *5032289 | PIN,CONNECTOR |
| 12 | 5030403 | BOLT |
| 14 | 5031222 | WASHER |
| 15 | 5031236 | SPACER |
| 1100 | 516011365 | Clutch Instruction Label |
| 1300 | 516011366 | Brake Guard Warning Label |
| 2330 | 516009931 | Tow Warning Decal |
| 2520 | 516009934 | Warning Decal |
| 3000 | 516009935 | Warning Decal, Hot liquid |
| 4500 | 516009927 | Decal - Label En/Fi/Swe |
| 4550 | 516011571 | Caution Hot Label |
| 4560 | 516011571 | Caution Hot Label |
| 5510 | 516011376 | Oil Information Label |
| 9510 | 516009807 | Instruction/Warning Label |
| 9550 | 516009930 | Warning Decal Rotating Track |
| 9560 | 516009911 | Warning Label |
