10- Electrical Harness Accessories
Parts (24)
| Ref | Part Number | Description |
|---|---|---|
| 61 | 409012900 | Male Terminal |
| 62 | 278001014 | Female Terminal |
| 63 | 409209400 | Male Terminal Housing, 2 Circuits |
| 70 | 409209700 | Female Housing, 4 Circuits |
| 73 | 278001013 | Wire Seal |
| 202 | 278001114 | Female Terminal |
| 229 | 278000223 | Female Terminal |
| 237 | 278000220 | Male Connector, 2 Circuits |
| 242 | 278000218 | Wire Seal |
| 243 | 710000048 | Wire Seal |
| 244 | 278000216 | Wire Seal |
| 295 | 278001008 | Insulated Sheath |
| 296 | 278000770 | Insulated Sheath |
| 297 | 278001007 | Insulated Sheath |
| 420 | 414115200 | Tie-Rap 180 mm |
| 474 | 278001481 | Female Terminal |
| 506 | 710000421 | Female Terminal |
| 751 | 710000918 | Female Terminal |
| 770 | 710001008 | Little Fuse, 3 AMP |
| 918 | 278002261 | Female Terminal |
| 938 | 278002299 | Female Terminal Housing 6 Circuits |
| 949 | 710000888 | Housing, 6 Circuits |
| 951 | 710001427 | Wire Seal |
| 1136 | 278002452 | HOUSING - Call your local BRP dealership |
