| Ref | Part Number | Description |
|---|
| 1 |
204613998 |
SEAT SUPPORT - Call your local BRP dealership |
| 2 |
293150043 |
Pop Rivet 3/16" |
| 3 |
234052400 |
Flat Washer 5 mm, Stainless |
| 4 |
204611940 |
SEAT LATCH - Call your local BRP dealership |
| 5 |
204100039 |
SCREW 1/4?-20 X 2? - Call your local BRP dealership |
| 6 |
204611805 |
LATCH - Call your local BRP dealership |
| 7 |
204100081 |
SCREW #8 X 1-1/4? - Call your local BRP dealership |
| 8 |
204615024 |
CAM LATCH - Call your local BRP dealership |
| 9 |
209641360 |
TAPPING PHILLIPS SCREW M4.2 X 13 - Call your local BRP dealership |
| 10 |
209641960 |
PHILLIPS TAPPING SCREW M4.2 X 19 - Call your local BRP dealership |
| 21 |
204100139 |
WASHER-FENDER/S.S. - Call your local BRP dealership |
| 22 |
211100026 |
HEX. NUT 1/4 - Call your local BRP dealership |
| 23 |
293730021 |
Dart |
