| Ref | Part Number | Description |
|---|
| 5 |
0318877 |
CRADLE, Clutch dog |
| 9 |
0318847 |
PROPELLER SHAFT |
| 10 |
704909038 |
Emblem Logo BRP 20 MM UV |
| 12 |
0316501 |
SHIFT, Clutch dog |
| 15 |
0386076 |
GEAR & BUSHING ASSY., Forward |
| 15 |
704909040 |
Emblem BRP Logo 48 MM UV |
| 17 |
0322341 |
PINION, Driveshaft This part replaces 0318862. |
| 18 |
0318800 |
THRUST WASHER, Lower pinion bearing |
| 19 |
0112840 |
THRUST BEARING, Pinion |
| 20 |
0318699 |
THRUST WASHER, Upper pinion bearing |
| 20 |
516011648 |
LH/RH Panel Decal |
| 21 |
0438617 |
GEARCASE Assy, This part replaces 0386017. |
| 25 |
0301877 |
O RING SHIFT ROD |
| 27 |
0306407 |
LOCCKWASHER,Cover latch |
| 32 |
0318966 |
THR BUSHING, Prop. to shaft |
| 38 |
0394711 |
CHROME PUMP KIT This part replaces 0318875. |
| 39 |
0394711 |
CHROME PUMP KIT This part replaces 0318999. |
| 40 |
0386084 |
IMPELLER |
| 41 |
0300611 |
AXE, turbine vers arbre d'entraînement |
| 42 |
0318995 |
PLATE, Impeller housing |
| 43 |
0318845 |
DRIVESHAFT, Standard |
| 43 |
0318846 |
DRIVESHAFT,Long 5" LONGER PARTS |
| 44 |
0302804 |
COTTER IN |
| 47 |
0318992 |
SHIFT ROD LOWER, Standard |
| 50 |
3048744 |
SCREW, Gearcase to exhaust housing |
| 51 |
0386669 |
PROPELLER AND BUSHING ASSEMBLY 10 X 5 |
| 51 |
0386670 |
PROPELLER AND BUSHING ASSEMBLY 9 X 10 |
| 51 |
0778772 |
RH Alum. 9 1/2 x 10 This part replaces 0386118. |
| 205 |
516011649 |
Central Hood Decal |
| 206 |
516011650 |
Central Hood Decal |
| 208 |
516011651 |
Square HE RS Decal |
| 212 |
516011652 |
LH/RH Panel Decal |
| 213 |
516011654 |
LH/RH Panel Decal |
| 425 |
516011655 |
LH/RH Tunnel Decal |
| 430 |
516011656 |
Snow Guard Decal |
| 435 |
516011657 |
Snow Guard Decal |
| 440 |
516011658 |
Snow Guard Decal |
| 604 |
516011659 |
LH/RH Radien Platform Decal |
| 605 |
516010682 |
Decal KYB Shock |
| 0386680 |
0438617 |
GEARCASE Assy, This part replaces 0386680. |
| 0386710 |
0392002 |
EXTENSION KIT ASSY. This part replaces 0386710. |
