| Ref | Part Number | Description |
|---|
| 1 |
511000559 |
Rear Light Support |
| 2 |
511000800 |
Rack Bar |
| 3 |
511000803 |
Rack bar fastening plate LH |
| 4 |
511000804 |
Rack bar fastening plate RH |
| 5 |
207662086 |
SCREW-HEX.FLANGE DIN.6921 - Call your local BRP dealership |
| 6 |
207561644 |
Hex Flange Screw M6 X 16, Scotch Grip |
| 7 |
207663534 |
HEX. FLANGED SCREW M6 X 35 - Call your local BRP dealership |
| 8 |
207662056 |
Socket Head Screw M6x20 8.8 |
| 9 |
NOT |
IN USE Flat Washer NOT IN USE |
| 10 |
511000657 |
SUPPORT HOSE - Call your local BRP dealership |
| 11 |
511000857 |
Alpine storage plate |
| 12 |
390909200 |
Avex Rivet |
| 13 |
860200768 |
ALPINE STORAGE BOX KIT - Call your local BRP dealership |
| 13 |
Not |
Available As Spare Part - Storage box |
| 14 |
Not |
Available As Spare Part - Storage box foam |
