| Ref | Part Number | Description |
|---|
| 10a |
715900435 |
U-Joint Cross Kit |
| 10b |
715900231 |
Yoke Joint |
| 10c |
703500815 |
Grease Fitting |
| 10d |
715900483 |
Cover |
| 25 |
Not |
Available As Spare Part - Non Applicable |
| 30a |
705501885 |
Drain Plug |
| 30b |
705401601 |
Screw |
| 30c |
705401602 |
Screw |
| 30d |
705401603 |
Nut |
| 30e |
705401604 |
Shim |
| 30f |
705401605 |
Ball Bearing |
| 30g |
705401606 |
Ball Bearing |
| 30h |
705402848 |
Ball Bearing This part replaces 705401607. |
| 30j |
705401608 |
Ball Bearing |
| 30k |
705401610 |
Front Cover |
| 30m |
705402841 |
Pinion 10 Teeth This part replaces 705401791. |
| 30n |
705401612 |
Gear 36 Teeth |
| 30p |
705401613 |
Vent Valve |
| 30r |
705401615 |
Oil Seal |
| 30s |
705401616 |
Seal |
| 30t |
705401617 |
O'Ring |
| 30u |
705401618 |
Gasket |
| 30v |
705401769 |
Shim |
| 30w |
705401770 |
Shim |
| 30x |
250200014 |
Flat Washer M10 |
| 30y |
250001046 |
Hex Flange Screw M10 X 20 S.Grip This part replaces 250000847. |
| 35 |
705500504 |
Fill Level Plug |
| 36 |
705500506 |
Copper Washer |
| 40a |
715900431 |
RH Plunging Joint |
| 40b |
715900427 |
CV Joint |
| 40c |
705401349 |
Circlip Joint |
| 40d |
705401345 |
Boot Kit, Wheel Side |
| 40e |
715900282 |
Oetiker Clamp |
| 40f |
715900283 |
Oetiker Clamp, Small |
| 40g |
705401346 |
Boot Kit, Differential Side |
| 40h |
715900284 |
Oetiker Clamp, Large |
| 40j |
715900261 |
Oetiker Clamp, Small |
| 45 |
705401548 |
LH Front Knuckle |
| 46 |
705401549 |
RH Front Knuckle |
| 50a |
715900430 |
LH Plunging Joint |
| 50b |
715900427 |
CV Joint |
| 50c |
705401349 |
Circlip Joint |
| 50d |
705401345 |
Boot Kit, Wheel Side |
| 50e |
715900282 |
Oetiker Clamp |
| 50f |
715900283 |
Oetiker Clamp, Small |
| 50g |
705401346 |
Boot Kit, Differential Side |
| 50h |
715900284 |
Oetiker Clamp, Large |
| 50j |
715900261 |
Oetiker Clamp, Small |
| 55 |
705400780 |
Wear Sleeve |
| 60 |
293350150 |
Ball Bearing This part replaces 293350118. |
| 80 |
293370019 |
Circlip |
| 90 |
207582044 |
Hex. Flange Screw M8 X 20, Scotch Grip |
| 100 |
230602546 |
Hex. Flange Screw M10 X 125 |
| 110 |
233201436 |
Hex. Flange Elastic Nut M10 |
| 150 |
250200171 |
Conical Spring Washer M18 |
| 160 |
232291413 |
Hex. Flange Castellated Nut M18 This part replaces 250100047. |
| 170 |
250400071 |
Cotter Pin |
| 180 |
219704410 |
Polyurethane Hose 10000Mm Long |
| 225 |
293000110 |
Valve Cap |
| 231 |
705402376 |
Differential This part replaces 703501006. |
| 310 |
250200014 |
Flat Washer M10 |
