08- Electric - Lower Section
Parts (31)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 0326877 | SPRING, Starter |
| 2 | 0324489 | SCREW, Spindle |
| 3 | 0391022 | PULLEY & PIN ASSEMBLY |
| 4 | 0316373 | SPINDLE |
| 5 | 0203700 | LINK SPRING TO PAWL |
| 6 | 0203698 | PAWL, Starter |
| 7 | 0316372 | FRICTIN SPRING |
| 8 | 0306799 | L'WASHER,Bracket to hsg. |
| 9 | ROPE, | Starter |
| 11 | 0325747 | HANDLE |
| 955 | 515178223 | Clip Connector |
| 3005 | 250001062 | Hex. Flanged Screw M6 X 16 |
| 3600 | 515178248 | Ground Wire |
| 3605 | 207662044 | Hex. Flange Screw M6 X 20 |
| 3607 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 |
| 3610 | 250000911 | Hex. Flange Screw M5 X 16 |
| 4100 | 278003012 | Starter Relay |
| 4200 | 515178919 | Positive Cable |
| 4205 | 710000495 | Protector Cap |
| 4210 | 232561434 | Elastic Stop Nut M6 |
| 4240 | 207551044 | Hex. Flange Screw M5 X 10 |
| 4327a | 250000282 | Battery Bolt Kit |
| 4330 | 710001817 | Protector Cap |
| 4340 | 515178695 | Battery Strip |
| 4350 | 515178690 | Battery Support Under |
| 4360 | 293150103 | Pop Rivet 3/16 |
| 4370 | 250000843 | Torx Truss Screw M6 X 30 |
| 4700 | 515178564 | Cable |
| 4720 | 207661644 | Hex. Flange Screw M6 X 16 |
| 4730 | 233261416 | Elastic Flanged Nut M6 X 1.0 |
| 0391035 | 0391035 | REWIND STARTER ASSY |
