| Ref | Part Number | Description |
|---|
| 1 |
616-00001-001 |
NEEDS DESCRIPTION This part replaces 3707-793. |
| 2 |
6706-615 |
Black, Front End Ass'y |
| 3 |
8060-484 |
Zinc Rivet |
| 4 |
6706-270 |
RH Reinforced Plate |
| 4 |
6706-271 |
LH Reinforced Plate |
| 5 |
8060-706 |
Black, Rivet |
| 6 |
0623-892 |
Self Tapping Screw 1/4-20X1/2 |
| 7 |
6706-367 |
Black, Front Belly Pan Bracket |
| 8 |
6706-786 |
Black, Footrest Support |
| 9 |
1623-797 |
Insert M5X0.8 |
| 10 |
2623-262 |
Blind Rivet 3/16 |
| 11 |
6716-016 |
RH Outer Plate Reinforcement |
| 11 |
6716-017 |
LH Outer Plate Reinforcement |
| 12 |
6706-440 |
Inner Plate Reinforcement |
| 13 |
6706-661 |
Black, Footrest Support Bracket PTD |
| 14 |
6716-164 |
Black, RH Rear Bumper End Cap |
| 14 |
6716-165 |
Black, LH Rear Bumper End Cap |
| 15 |
8060-486 |
Zinc Rivet |
| 16 |
2623-221 |
Blind Rivet 5/32 |
| 17 |
6716-163 |
Black, Tunnel Cover Plate PTD |
| 18 |
2623-261 |
Blind Rivet 5/32 |
| 19 |
2612-707 |
Spring Tab |
| 20 |
8060-686 |
Zinc Blind Rivet |
| 21 |
0617-796 |
Fuel Tank Pad |
| 22 |
6706-274 |
Black, Front Bumper |
| 23 |
414115200 |
Tie-Rap 180 mm |
| 24 |
0623-677 |
Tie Wrap Clip |
| 25 |
0630-349 |
DC, Regulator |
| 26 |
0630-365 |
AC Regulator |
| 27 |
6716-160 |
RH Footrest |
| 27 |
6716-161 |
LH Footrest |
| 28 |
6706-273 |
Black, Rear Bumper |
| 29 |
8422-502 |
Nut |
| 30 |
0123-802 |
Flat Washer |
| 31 |
8060-504 |
Black, Rivet |
| 32 |
1616-355 |
Snow Guard |
| 33 |
2623-164 |
Self Tapping Screw #10-12X1/2 |
| 34 |
1623-939 |
U Type Nut |
| 35 |
5611-852 |
Towing Warning Decal (French) |
| 36 |
5611-853 |
Towing Warning Decal (English) |
| 37 |
6606-819 |
Decal Amber Reflector |
| 38 |
8047-426 |
Elastic Stop Nut 1/4-20 |
| 39 |
6706-441 |
Black, Bracket |
| 40 |
8020-131 |
Cap Screw 5/16-18 |
| 41 |
3707-631 |
Clutch Guard With Decal |
| 42 |
5621-854 |
Decal , Jet Chart 200 |
| 43 |
1611-565 |
Belt Guard Warning Decal |
| 44 |
4604-452 |
Axle X-Brace |
| 45 |
1623-637 |
U-Nut Clip M5 |
| 46 |
8476-516 |
Machine Screw M5X0.8 |
| 47 |
6716-162 |
Black, Disc Brake Guard |
| 48 |
8060-702 |
Black, Rivet |
| 49 |
3707-134 |
Tunnel Guard |
| 50 |
2623-276 |
Flat Washer |
| 51 |
8060-508 |
Black, Rivet |
| 52 |
0706-371 |
Rack Trim 36 |
| 53 |
8477-620 |
Machine Screw |
| 54 |
8427-602 |
Hex Flanged Elastic Nut M6X1.0 |
