| Ref | Part Number | Description |
|---|
| 2 |
420664312 |
Engine Wiring Harness |
| 3 |
420664450 |
ECM Connector |
| 4 |
420966970 |
TEMPERATURE SENSOR - Call your local BRP dealership |
| 5 |
270600040 |
Pressure Sensor This part replaces 420274055. |
| 6 |
278001546 |
Ignition Coil This part replaces 420266070. |
| 7 |
420665333 |
Spark Plug Cable, 790 mm, Rear This part replaces 420664300. |
| 8 |
420660632 |
SLEEVE, MAG SIDE - Call your local BRP dealership |
| 9 |
420664305 |
CABLE ASS?Y 245 MM PTO - Call your local BRP dealership |
| 10 |
420660630 |
SLEEVE, PTO SIDE - Call your local BRP dealership |
| 11 |
278000237 |
SPARK PLUG CAP - Call your local BRP dealership |
| 12 |
415128524 |
Spark Plug NGK BR9ECS |
