| Ref | Part Number | Description |
|---|
| 2 |
204061154 |
PLUG - Call your local BRP dealership |
| 3 |
204061153 |
Barbed Fitting |
| 4 |
204130188 |
FITTING - Call your local BRP dealership |
| 5 |
204130189 |
ELBOW FITTING - Call your local BRP dealership |
| 6 |
212000005 |
NUT-STOP ELASTIC MS-17830 - Call your local BRP dealership |
| 7 |
234062600 |
Flat Washer M6, Stainless |
| 8 |
293650016 |
Tridon Clamp |
| 9 |
293650019 |
Tridon Gear Clamp |
| 10 |
291001206 |
BILGEFLEX HOSE 3/4, BLACK, METER - Call your local BRP dealership |
| 11 |
293710162 |
Fitting This part replaces 293710015. |
| 12 |
293250006 |
GASKET - Call your local BRP dealership |
| 13 |
204061123 |
HOSE, 19 MM - Call your local BRP dealership |
| 14 |
204061017 |
THRU HULL FITTING, 3/4 - Call your local BRP dealership |
| 15 |
219704455 |
Was 293800018 Loctite 592, 50 ml |
| 16 |
204100165 |
Flange Nut 3/4", Bronze |
| 17 |
204061013 |
Shut-Off Valve |
| 18 |
204061016 |
Adapter |
| 19 |
204061123 |
HOSE, 19 MM - Call your local BRP dealership |
