| Ref | Part Number | Description |
|---|
| 1 |
5007423 |
Kit Ay This part replaces 0174619. |
| 2 |
0333632 |
HOSE, Connector to filter |
| 3 |
HOSE, |
Tee to vacuum switch, 8" long |
| 5 |
0397502 |
BYPASS VALVE |
| 6 |
0330522 |
WAVE WASHER, Vacuum switch |
| 8 |
0331623 |
FILTER AND HOSE ASSY. |
| 10 |
0586544 |
VACUUM SWITCH This part replaces 0395208. |
| 13 |
0328600 |
TERMINAL GROMMET |
| 14 |
0330448 |
SCREW, Switch lead |
| 16 |
HOSE, |
Oil line, fitting to conn., 26" long |
| 17 |
0322654 |
PINCE RAPIDE, flexible d'huile |
| 18 |
PULSE |
HOSE, 6-1/4" long |
| 19 |
HOSE, |
Fuel connector to fitting 30" long |
| 20 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 21 |
0333399 |
HOSE, Fitting to lower pump |
| 22 |
0331062 |
FITTING, Oil hose |
| 23 |
0333400 |
HOSE, Fitting to upper pump |
| 24 |
0331055 |
FITTING, Fuel hose |
| 26 |
0332244 |
GROMMET |
| 27 |
0329661 |
SUPPORT/BOUCHON |
| 28 |
HOSE, |
Valve to manifold, 10-3/4" long (port) |
| 29 |
0333410 |
HOSE, Fuel connector to filter |
| 29 |
HOSE, |
Valve to manifold, star 16" long |
| 30 |
HOSE, |
Sight tube to pump 1-1/2" |
| 31 |
0912552 |
HOSE, Fitting to sight tube |
| 32 |
0122147 |
VIS, connecteur |
| 33 |
0331443 |
SPIRAL TUBE, Oil line, upper |
| 35 |
0331649 |
CAP, Connector - fuel |
| 36 |
0329653 |
CLAMP |
| 37 |
0332245 |
CONNECTOR, Fuel & oil hose |
| 3001 |
515178435 |
Diagnostic Cap |
| 3005 |
250001062 |
Hex. Flanged Screw M6 X 16 |
| 3600 |
515178248 |
Ground Wire |
| 3605 |
207662044 |
Hex. Flange Screw M6 X 20 |
| 3607 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 3610 |
250000911 |
Hex. Flange Screw M5 X 16 |
| 4320 |
515178891 |
Ultracapacitor Module |
| 4321 |
233151414 |
Nut Flange Hex. M5 |
| 4322 |
515178698 |
Heat Shield |
| 4323 |
707000746 |
Rubber Mount |
| 4327 |
415130653 |
Battery YUASA YTX4L-BS This part replaces 515179329. |
| 4328 |
515179279 |
Battery Support |
| 4330 |
710001817 |
Protector Cap |
| 4340a |
293450275 |
Insert |
| 4370 |
207151244 |
Hex. Screw M5 X 12 |
| 4371 |
391301600 |
Washer |
| 4700 |
515178155 |
Ground Wire |
| 4720 |
207661644 |
Hex. Flange Screw M6 X 16 |
