| Ref | Part Number | Description |
|---|
| ACC1 |
515178014 |
Female Terminal |
| ACC2 |
515178014 |
Female Terminal |
| COM |
710002705 |
Lock |
| COM |
710002706 |
Female Housing, 6 Circuits |
| COM |
710005438 |
Female Terminal |
| COM |
710005439 |
Female Terminal |
| ECMB |
710001589 |
Female Terminal |
| ECMB |
710001591 |
Cover, 48 positions |
| ECMB |
710001592 |
Plug |
| ECMB |
710001727 |
Female Terminal |
| ECMB |
710001967 |
Molex Housing, 48 Circuits |
| ECO |
515178302 |
Female Terminal |
| FA |
278000805 |
Cap Holder - Fuse |
| FA |
278001325 |
Fuse Holder |
| FA |
278001326 |
Fuse Holder Cap |
| FA |
710000357 |
Female Terminal |
| FA |
710001613 |
Fuse |
| FAN |
278000217 |
Female Housing, 2 Circuits |
| FAN |
278000218 |
Wire Seal |
| FAN |
409004300 |
Male Terminal |
| FB1 |
278000218 |
Wire Seal |
| FB1 |
278002880 |
Seal Plug |
| FB1 |
710000890 |
Female Terminal |
| FB1 |
710000918 |
Female Terminal |
| FB1C |
710000744 |
Little Fuse, 10 Ampere |
| FB1C |
710000745 |
Little Fuse, 15 Ampere |
| FB1C |
710000746 |
Little Fuse, 20 Ampere |
| FB2 |
710000274 |
Female Terminal |
| FB2 |
710006126 |
Female Terminal |
| FP |
515178018 |
Female Terminal |
| FP |
515178474 |
Female Housing |
| GND |
278001392 |
Open Barrel Terminal |
| HIC |
278003535 |
Female Housing, 4 circuits |
| HIC |
515178018 |
Female Terminal |
| HL1 |
515178006 |
Female Housing |
| HL1 |
710001228 |
Terminal |
| HL1 |
710001332 |
Seal Wire |
| HL2 |
515178006 |
Female Housing |
| HL2 |
710001228 |
Terminal |
| HL2 |
710001332 |
Seal Wire |
| HO2S1 |
278001482 |
Seal |
| HO2S1 |
515178661 |
Lock |
| HO2S1 |
710000736 |
Terminal |
| HO2S1 |
710000992 |
Clip |
| HO2S1 |
710002466 |
Housing |
| HO2S1 |
710002597 |
Gold Terminal |
| MG |
278002858 |
Female Housing 20 Circuits |
| MG |
515178014 |
Female Terminal |
| MG |
515178018 |
Female Terminal |
| REG |
710000879 |
Female Housing, 3 Circuits |
| REG |
710000882 |
Cap |
| REG |
710001932 |
Seal |
| REG |
710001934 |
Terminal |
| RFID |
710001161 |
Housing |
| RFID |
710001163 |
Wire Seal |
| RFID |
710001164 |
Female Terminal |
| RY1 |
715900824 |
Relay This part replaces 710001778. |
| RY2 |
515176774 |
Relay, 30 AMP |
| RY3 |
715900824 |
Relay This part replaces 710001778. |
| RY4 |
515176774 |
Relay, 30 AMP |
| RY5 |
715900824 |
Relay This part replaces 710001778. |
| RY6 |
715900824 |
Relay This part replaces 710001778. |
| SD |
515177192 |
Female Housing, 2 Circuits |
| SD |
710000925 |
Terminal |
| SD |
710001332 |
Seal Wire |
| SH |
515178013 |
Male Terminal |
| TAS |
710000992 |
Clip |
| TAS |
710001224 |
Terminal |
| TAS |
710001231 |
Housing |
| TAS |
710001233 |
Seal |
| TL |
515178014 |
Female Terminal |
| TL |
515178018 |
Female Terminal |
| TL |
515178346 |
Female Housing Connector 4 Pins W/O CPA |
| VSS |
515178018 |
Female Terminal |
| 1 |
0583428 |
FLYWHEEL ASSY. |
| 2 |
0333263 |
NUT, Flywheel |
| 3 |
0325042 |
SCREW, Starter mounting |
| 4 |
0583410 |
STATOR ASSY., 3/9 amp |
| 9 |
0583508 |
TIMER BASE & SENSOR ASSY. |
| 14 |
0326439 |
CLAMP, Leads |
| 15 |
0313666 |
RET., Distributor base 1 |
| 16 |
0584183 |
ENGINE CABLE ASSY. |
| 29 |
0304027 |
VIS, arbre de commande de sens de marche |
| 32 |
0582508 |
COIL ASSY |
| 33 |
0584041 |
POWER PACK |
| 52 |
0512656 |
TERMINAL BLOCK |
| 53 |
0582365 |
H.T. LEAD ASSEMBLY, Spark plugs to ignition coil |
| 56 |
0583997 |
ELECTRICAL BRACKET ASSY. |
| 57 |
0584205 |
RECTIFIER & REGULATOR ASSY. |
| 59 |
0331980 |
SCREW, Bracket, port |
| 60 |
0334109 |
BOLT, Double end |
| 62 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 65 |
0311217 |
MANCHON, solénoïde |
| 66 |
0330112 |
BRIDE, solénoïde vers démarreur |
| 73 |
0306644 |
VIS, capteur de papillon |
| 75 |
0393354 |
NUT SPRING & SPACER KIT |
| 76 |
0393354 |
NUT SPRING & SPACER KIT This part replaces 0316740. |
| 78 |
0385949 |
DRIVE ASSY |
| 81 |
0318584 |
AMRMATURE |
| 82 |
0385844 |
CAP ASSY COMMUTATOR This part replaces 0328381. |
| 90 |
0329240 |
SCREW |
| 93 |
0585146 |
INTERRUPTEUR CORRECTION D'ASSIETTE/RELEVAGE This part replaces 0583803. |
| 98 |
0330368 |
BUSHING, Timber base |
| 100 |
0583909 |
CABLE, Junction box switch |
| 114 |
0333845 |
DECAL, Terminal block wiring |
| 116 |
0329168 |
SOCKET |
| 3000 |
515178936 |
Chassis Wiring Harness |
| 0393570 |
0393570 |
STARTER MOTOR ASSY. |
