| Ref | Part Number | Description |
|---|
| 1 |
5008623 |
FUEL TANK This part replaces 0381015. |
| 2 |
0304888 |
SCREW |
| 4 |
0310849 |
HOUSING ASSY., Valve |
| 5 |
0312191 |
SCREW, Indicator support |
| 6 |
0312190 |
LENS |
| 7 |
0332505 |
SEAL This part replaces 0312192. |
| 9 |
0398459 |
FLOAT & INDICATOR This part replaces 0310845. |
| 10 |
0312193 |
GASKET |
| 10 |
517306816 |
Center Hood |
| 11 |
250000528 |
Torx Screw M5 X 20 |
| 12 |
0125530 |
GASKET, Housing to tank This part replaces 0310984. |
| 12 |
250000958 |
Panel Nut M5 X 0.8 |
| 13 |
0377536 |
FEUL TANK CAP ASSY |
| 13 |
517307086 |
RH Front Hood |
| 14 |
250000528 |
Torx Screw M5 X 20 |
| 15 |
250000958 |
Panel Nut M5 X 0.8 |
| 16 |
0398409 |
HOUSING This part replaces 0381016. |
| 16 |
517307087 |
LH Front Hood |
| 17 |
517306684 |
Hood Grill |
| 20 |
0332488 |
RING, Quad This part replaces 0307858. |
| 20 |
250000528 |
Torx Screw M5 X 20 |
| 29 |
0306801 |
CLAMP, Hose, small |
| 30 |
250000958 |
Panel Nut M5 X 0.8 |
| 34 |
0373720 |
VALVE, Outlet |
| 35 |
0373719 |
VALVE, Inlet |
| 100 |
517307222 |
RH Upper Side Panel |
| 105 |
517308487 |
RH Upper Side Panel Foam |
| 110 |
250000725 |
Screw M4 X 16 |
| 120 |
250000528 |
Torx Screw M5 X 20 |
| 130 |
250000958 |
Panel Nut M5 X 0.8 |
| 150 |
517306069 |
LH Upper Side Panel |
| 155 |
517308488 |
LH Upper Side Panel Foam |
| 160 |
250000725 |
Screw M4 X 16 |
| 170 |
250000528 |
Torx Screw M5 X 20 |
| 180 |
250000958 |
Panel Nut M5 X 0.8 |
| 200 |
517307341 |
Rear Console |
| 210 |
250000958 |
Panel Nut M5 X 0.8 |
| 220 |
250000587 |
Torx Screw M5 X 26 |
| 230 |
250000587 |
Torx Screw M5 X 26 |
| 240 |
517306398 |
Foam Console |
| 245 |
517304518 |
Console Nut |
| 250 |
732610072 |
Push Nut |
| 360 |
517306808 |
Switch Hole Cap |
| 500 |
517306918 |
RH Cover Plate |
| 510 |
517306919 |
LH Cover Plate |
| 600 |
517307441 |
Gauge Support |
| 800b |
517306183 |
Deep Black, Windshield Support |
| 800c |
732610072 |
Push Nut |
| 800d |
517306895 |
RH Upper Air Deflector |
| 800f |
517306894 |
LH Upper Air Deflector |
| 800g |
250000889 |
Screw M4 X 16 |
| 800h |
250200024 |
Rubber Washer 5 mm |
| 810 |
517303756 |
Grommet |
| 2400a |
415130081 |
Bulb |
| 2810 |
517307161 |
Grommet |
| 3010 |
517307161 |
Grommet |
| 3200b |
517305779 |
Latch |
| 3200c |
732610072 |
Push Nut |
| 3400b |
517305157 |
Seal Joint |
| 3800 |
517306824 |
Black, Head Lamp Bezel |
| 3810 |
250000528 |
Torx Screw M5 X 20 |
| 3820 |
250000958 |
Panel Nut M5 X 0.8 |
| 0383721 |
0383721 |
HOSE & PRIMER BLUB ASSEMBLY |
