| Ref | Part Number | Description |
|---|
| 1 |
0310956 |
DRIVE PIN |
| 2 |
3852477 |
GASKET, Pump to block This part replaces 0909835. |
| 3 |
0909852 |
GASKET, Port |
| 4 |
0909786 |
GASKET |
| 5 |
0909836 |
PLATE, Elbow, water shut off |
| 6 |
0910416 |
HOUSING, Block outlet |
| 7 |
0910419 |
BRACKET, Heat exchange port |
| 8 |
0910422 |
BRACKET, Heat exchange starboard |
| 9 |
0301431 |
SCREW |
| 10 |
0306414 |
SCREW |
| 11 |
0120177 |
L'WASHER, Alternator to brkt |
| 14 |
0909842 |
PAD, Bracket, heat exchanger |
| 15 |
0909864 |
NIPPLE, Water pump by-pass |
| 16 |
0910400 |
HOSE, Thermostat housing to water pump |
| 17 |
0910401 |
HOSE, Heat exchanger to manifold, port |
| 18 |
0910402 |
HOSE, Thermostat housing to manifold, starboa |
| 19 |
0910407 |
HOSE, Heat exchanger to high rise, starboard |
| 20 |
0910408 |
HOSE, Heat exchanger to high rise, port |
| 21 |
0910410 |
HOSE, Heat exchange to water pump |
| 22 |
0910403 |
HOSE, Manifold to block housing, port |
| 23 |
0910404 |
HOSE, Manifold to block housing, starboard |
| 24 |
0910412 |
HOSE, Pump to heat exchanger |
| 25 |
0910405 |
HOSE, Oil Cooler to connector |
| 25 |
0910406 |
HOSE, Intermediate housing to connector |
| 26 |
0910411 |
HOSE, Sea water pump to connector |
| 27 |
0910413 |
CONNECTOR, Hose |
| 28 |
0982889 |
HEAT EXCHANGER & THERMOSTAT HOUSING |
| 30 |
0306450 |
SCREW |
| 31 |
0306453 |
LOCKWASHER, Fuel pump |
| 33 |
0910398 |
THERMOSTAT HOUSING |
| 34 |
0910399 |
GASKET, Thermostat housing |
| 35 |
0981966 |
TERHMOSTAT |
| 36 |
0306414 |
SCREW |
| 38 |
0912627 |
CLAMP This part replaces 0313851. |
| 39 |
0979803 |
CLAMP |
| 40 |
3853786 |
CLAMP INSTRUMENT CABLE This part replaces 0980577. |
| 41 |
3852604 |
CLAMP, Exhaust This part replaces 0981323. |
| 42 |
0982013 |
COOLANT RECOVERY KIT |
| 43 |
0910471 |
NIPPLE, High rise elbow |
| 44 |
0982669 |
WATER PUMP ASSEMBLY |
| 45 |
0982301 |
IMPELLER & GASKET KIT |
| 46 |
0982300 |
IMPELLER BEARING & SEAL KIT |
| 47 |
0910420 |
PULLEY ASSY |
| 48 |
0910127 |
SPACER, Puller to brg (1) |
| 49 |
0548323 |
RETAINING RING |
| 50 |
0910126 |
SPACER, Bearing |
| 51 |
0982299 |
BEARING |
| 52 |
3854295 |
END PLATE This part replaces 0910131. |
| 53 |
0982298 |
SEAL & SEAT ASSY |
| 54 |
0910130 |
CAM, Impeller |
| 55 |
0910132 |
IMPELLER |
| 56 |
3854293 |
O-RING, Housing This part replaces 0909694. |
| 57 |
3854296 |
GASKET, Plate to body This part replaces 0910134. |
| 58 |
3854297 |
SCREW, Body to hsg. This part replaces 0910135. |
| 59 |
3854292 |
LOCK WASHER, Screw to hsg. This part replaces 0304145. |
| 60 |
0910123 |
BODY |
| 61 |
0910121 |
RETAINING RING |
| 62 |
0910122 |
THRUST WASHER, Seal |
| 63 |
3854294 |
KEY, Impeller This part replaces 0910120. |
| 63A |
0910444 |
SHAFT |
| 64 |
0910118 |
HOUSING |
| 65 |
0910119 |
SCREW, Cam |
| 66 |
0308419 |
WASHER |
| 68 |
0302479 |
VIS, démarreur vers bloc cylindres-carter This part replaces 0306416. |
| 69 |
0910424 |
BRACKET, Water pump |
| 70 |
0910414 |
BELT |
| 71 |
0306414 |
SCREW |
| 72 |
0120177 |
L'WASHER, Alternator to brkt |
| 73 |
0910075 |
CLAMP, Hose to manifold |
| 74 |
3751232 |
PULLEY |
| 332 |
0908276 |
CAP PLUG |
