| Ref | Part Number | Description |
|---|
| 10a |
715900118 |
Rubber Boot |
| 10b |
509000045 |
Oetiker Gear Clamp 36.1MM |
| 15 |
705401093 |
Rubber Boot |
| 16 |
293650199 |
Oetiker Gear Clamp |
| 20 |
705401969 |
Coupling Sleeve |
| 25a |
703500678 |
Front Bushing Shaft Kit |
| 30 |
703500908 |
Front Differential |
| 30s |
705401615 |
Oil Seal |
| 40a |
715900428 |
JOINT_CV EXT - Call your local BRP dealership |
| 40b |
715900395 |
RH Plunging CV Joint |
| 40c |
705401349 |
Circlip Joint |
| 40d |
705401354 |
Boot Kit, Wheel Side |
| 40e |
715900260 |
Oetiker Clamp, Large |
| 40f |
715900261 |
Oetiker Clamp, Small |
| 40g |
705401355 |
Boot Kit, Différential Side |
| 40h |
715900261 |
Oetiker Clamp, Small |
| 40j |
715900262 |
Oetiker Clamp, Large |
| 45 |
705403307 |
LH Knuckle This part replaces 705401290. |
| 46 |
705403308 |
RH Knuckle This part replaces 705401291. |
| 50a |
705401407 |
CV Joint |
| 50b |
715900396 |
LH Plunging CV Joint |
| 50c |
705401349 |
Circlip Joint |
| 50d |
705401354 |
Boot Kit, Wheel Side |
| 50e |
715900260 |
Oetiker Clamp, Large |
| 50f |
715900261 |
Oetiker Clamp, Small |
| 50g |
705401355 |
Boot Kit, Différential Side |
| 50h |
715900261 |
Oetiker Clamp, Small |
| 50j |
715900262 |
Oetiker Clamp, Large |
| 60 |
293350150 |
Ball Bearing This part replaces 293350118. |
| 70 |
293650138 |
Oetiker Gear Clamp 44.0MM |
| 80 |
293370019 |
Circlip |
| 150 |
250200171 |
Conical Spring Washer M18 |
| 160 |
232291413 |
Hex. Flange Castellated Nut M18 |
| 170 |
250400071 |
Cotter Pin |
| 240 |
250200102 |
Flat Washer M12 |
| 250 |
250001042 |
Hex Flange Screw M12 X 20 |
| 310 |
250200014 |
Flat Washer M10 |
| 320 |
250001046 |
Hex Flange Screw M10 X 20 S.Grip |
