| Ref | Part Number | Description |
|---|
| 1 |
0435430 |
EXHAUST HOUSING ASSY. |
| 7 |
0342540 |
SCREW, Exhaust housing to ext. |
| 9 |
0437894 |
MOUNT ASSY., Upper |
| 10 |
0329021 |
MOUNT BRACKET, Lower port |
| 10 |
503195703 |
Runner |
| 11 |
0329020 |
MOUNT BRACKET, Lower, stbd |
| 12 |
0330440 |
EXHAUST TUBE, Inner |
| 13 |
0339734 |
THRUST MOUNT, Upper |
| 14 |
0319229 |
GROMMET, Exh, hsg, to shift rod |
| 15 |
0342541 |
PLATE, Upper mount |
| 16 |
0395125 |
TUBE, Water outlet |
| 18 |
0395122 |
WATER TUBE & GROMMET, Inlet, std. |
| 18 |
0395123 |
EATER TUBE, Long |
| 18 |
0395124 |
WATER TUBE |
| 20 |
0329046 |
THRUST MOUNT |
| 20 |
503196124 |
Slider Shoe |
| 21 |
0325721 |
GASKET, Cyl. & c'case to lower engine cover |
| 22 |
0339809 |
SCREW, Outer exh. hsg. to powerhead, long |
| 23 |
0339666 |
COVER, Upper mount |
| 25 |
0319042 |
SCREW BRACKET AND CLAMPSCREW ASSY., Port |
| 27 |
0318997 |
LATERAL MOUNT, Lower |
| 28 |
0339676 |
O-RING, Cover |
| 30 |
0329241 |
RONDELLE |
| 30 |
208562531 |
Phillips Screw M6 X 25 |
| 31 |
0338445 |
DECAL, Exh. hsg., Ev., 90/100/115, except Jet |
| 40 |
232561434 |
Elastic Stop Nut M6 |
| 60 |
503194790 |
Front Wheel Shaft |
| 70a |
503190396 |
Ball Bearing |
| 70b |
415129371 |
Retaining Ring |
| 80 |
205504544 |
Socket Screw |
| 90 |
234001410 |
Flat Washer 10 mm |
| 200 |
503193504 |
Rubber Stopper |
| 210 |
293150224 |
Rivet Pop 3/16 |
| 220 |
503191273 |
Washer |
| 230 |
503195028 |
Rubber Stopper |
| 240 |
293150224 |
Rivet Pop 3/16 |
| 250 |
503191273 |
Washer |
| 260 |
503191291 |
Rubber Stopper |
| 270 |
293150224 |
Rivet Pop 3/16 |
| 280 |
503191273 |
Washer |
| 310a |
503190396 |
Ball Bearing |
| 310b |
415129371 |
Retaining Ring |
| 311 |
503196122 |
Wheel |
| 320a |
503190396 |
Ball Bearing |
| 320b |
415129371 |
Retaining Ring |
| 330 |
503193894 |
Casted Support |
| 331 |
503193894 |
Casted Support |
| 340 |
250000944 |
Hex. Flange Screw M6 X 70 |
| 341 |
250000944 |
Hex. Flange Screw M6 X 70 |
| 345 |
207068044 |
Screw Hex. M6 X 80 |
| 350 |
503191820 |
Wheel Cup M6 |
| 351 |
503191820 |
Wheel Cup M6 |
| 360 |
233261466 |
Hex. Flanged Elastic Nut M6 |
| 361 |
233261466 |
Hex. Flanged Elastic Nut M6 |
| 370 |
250000945 |
Hex. Flange Screw M6 X 25 |
| 371 |
250000945 |
Hex. Flange Screw M6 X 25 |
| 390 |
503195345 |
Black, Wheel Cap |
| 391 |
503195345 |
Black, Wheel Cap |
| 400 |
503192771 |
Black, Wheel Cap |
| 2430 |
503195279 |
Center Shock Shaft |
| 2440 |
503195044 |
Spacer |
| 2445 |
503195045 |
Spacer |
| 2450 |
503189276 |
Washer |
| 2460 |
205523554 |
Socket Head Screw M12 X 35 |
| 2500 |
503195022 |
LH Rail Pivot Ass'y |
| 2505 |
503195023 |
RH Rail Pivot Ass'y |
| 2510 |
503194971 |
Pivot Spring |
| 2520 |
503194763 |
Ball Joint Link |
| 2530 |
503192491 |
Washer |
| 2550 |
233281464 |
Elastic Flange Nut M8 |
| 2560 |
207683544 |
Hex. Flange Screw M8 X 35 |
| 2570 |
232581414 |
Hex. Elastic Stop Nut M8 |
| 2580 |
503196408 |
Extension Spring Support |
| 2590 |
207662556 |
Hex. Flange Screw M6 X 25 |
| 2600 |
233261466 |
Hex. Flanged Elastic Nut M6 |
| 2610 |
503195064 |
Tensioner |
| 2620 |
250000983 |
Hex. Cap Screw With Nylon Patch |
| 2630 |
250200111 |
Washer |
| 2660 |
503194641 |
Lower Shaft |
| 2670 |
503192491 |
Washer |
| 2680 |
250000537 |
Hex. Cap Screw M12 X 35 |
| 2690 |
706200281 |
Hardened Washer |
| 2800 |
503191408 |
Rear Axle |
| 2810 |
503193051 |
Spacer |
| 2820 |
503194648 |
Spacer |
| 2830 |
503194647 |
Spacer |
| 2840a |
503190396 |
Ball Bearing |
| 2840b |
415129371 |
Retaining Ring |
| 2850 |
31013 |
Shim Ring |
| 2870a |
503190396 |
Ball Bearing |
| 2870b |
415129371 |
Retaining Ring |
| 2880 |
503190439 |
Washer |
| 2890 |
250000817 |
Hex Screw With Nilon Patch, M10 X 35 |
