| Ref | Part Number | Description |
|---|
| 2 |
204610150 |
Front Backrest Cover (Indigo) |
| 3 |
216554060 |
Screw M5 x 40 |
| 4 |
269000388 |
SEAT SUPPORT - Call your local BRP dealership |
| 5 |
293150043 |
Pop Rivet 3/16" |
| 6 |
234061600 |
Stainless Flat Washer M6 This part replaces 213200001. |
| 7 |
293800060 |
Loctite 243, 10 ml This part replaces 293800015. |
| 9 |
204610170 |
Rear Bump Cover (Indigo) |
| 10 |
204610171 |
Rear Backrest Cover (1 pass.) (White/Emb |
| 11 |
204610172 |
Rear Backrest Cover (White/Serigraphy) |
| 12 |
207164060 |
Hex. Screw M6 X 40 This part replaces 210000012. |
| 13 |
234062600 |
Flat Washer M6, Stainless This part replaces 213200007. |
| 15 |
204610224 |
Rear Seat Cover (Indigo) |
| 16 |
204610307 |
Rear Seat Pillow Cover |
| 18 |
204610109 |
LH Rear Seat Pillow Cover |
| 19 |
204610226 |
Strap (80 cm.) |
| 20 |
207161660 |
Hex. Screw M6 X 16 This part replaces 215061660. |
| 21 |
234062600 |
Flat Washer M6, Stainless This part replaces 213200007. |
| 22 |
204610227 |
Strap (50 cm.) |
| 23 |
232561600 |
Hex. Elastic Stop Nut M6 This part replaces 212000001. |
| 24 |
207162060 |
Hex. Forming Screw M6 X 20 This part replaces 210000004. |
| 26 |
204610168 |
Keeper Seat Backrest Cover |
| 27 |
216553060 |
Set Screw M5 x 30 |
| 28 |
232051600 |
Hex. Nut M5 This part replaces 218051600. |
| 29 |
293800005 |
Loctite 271, 10 ml |
| 30 |
232551600 |
Hex. Elastic Nut M5 This part replaces 212000004. |
| 32 |
204610165 |
Keeper Seat Cover (Large) |
| 34 |
204610217 |
Keeper Seat Ring Cover |
| 35 |
277000584 |
SPACER 6.7 MM - Call your local BRP dealership |
| 36 |
216663260 |
Screw 6.3 x 32 |
| 37 |
234161601 |
Lock Washer Helical M6 This part replaces 217361500. |
| 38 |
293730014 |
Black Dart |
| 40 |
204610212 |
RH Rear Seat Arm-Rest Cover |
| 41 |
204610153 |
Center Front Seat Cover (White) |
| 42 |
207164560 |
Hex. Screw M6 X 45 This part replaces 215064560. |
| 43 |
293150008 |
Pop Rivet 3/16" This part replaces 293150011. |
| 44 |
204610184 |
Staple Cover, Meter |
| 45 |
204070055 |
BLACK TRIM, METER - Call your local BRP dealership |
| 46 |
234052600 |
Flat Washer 5 mm, Stainless This part replaces 213200015. |
| 47 |
234082600 |
Flat Washer 8 mm, Stainless This part replaces 213200011. |
| 48 |
204610178 |
Front Seat Latch |
| 49 |
204610207 |
Seat Stud |
| 50 |
293830043 |
Rubber Stopper |
| 51 |
293150013 |
Pop Rivet 3/16" |
| 52 |
293000060 |
Passenger Strap |
| 53 |
234042600 |
Flat Washer 4 mm, Stainless This part replaces 217042600. |
| 54 |
241140060 |
Screw K40 X 10 This part replaces 211000028. |
| 56 |
204610156 |
LH Front Seat Cover (White) |
| 57 |
204610184 |
Staple Cover, Meter |
| 58 |
205441660 |
Socket Head Screw M4 X 16 This part replaces 211000086. |
| 59 |
204610178 |
Front Seat Latch |
| 61 |
205441660 |
Socket Head Screw M4 X 16 This part replaces 211000086. |
| 62 |
232561600 |
Hex. Elastic Stop Nut M6 This part replaces 212000001. |
| 63 |
204610257 |
Backrest Pin |
| 65 |
204610161 |
LH Front Backrest Cover |
| 66 |
204610184 |
Staple Cover, Meter |
| 67 |
204610178 |
Front Seat Latch |
| 68 |
205441660 |
Socket Head Screw M4 X 16 This part replaces 211000086. |
| 69 |
208663060 |
PHILLIPS SCREW M6 X 30 - Call your local BRP dealership This part replaces 215863068. |
| 70 |
293730005 |
Staple |
