| Ref | Part Number | Description |
|---|
| 210 |
705010721 |
Clip |
| 3400 |
715006594 |
Black, LH Front Lateral Panel Kit This part replaces 715004064. |
| 3410 |
250000722 |
Torx Screw M6 X 20 |
| 3411 |
250000712 |
Torx Screw M6 X 20 |
| 3412 |
250000807 |
Torx Truss Screw M6 X 25 |
| 3415 |
233261494 |
Hex. Flange Elastic Nut M6 |
| 3420 |
250100242 |
Threaded Insert M6 X 1.0 This part replaces 293450274. |
| 3430 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000957. |
| 3440 |
250000868 |
Torx Truss M6 X 50 |
| 3500 |
715004074 |
RH Front Lateral Panel Kit |
| 3510 |
250000722 |
Torx Screw M6 X 20 |
| 3511 |
250000712 |
Torx Screw M6 X 20 |
| 3515 |
233261494 |
Hex. Flange Elastic Nut M6 |
| 3520 |
250100242 |
Threaded Insert M6 X 1.0 This part replaces 293450274. |
| 3530 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000957. |
| 3540 |
250000868 |
Torx Truss M6 X 50 |
| 3550 |
233261494 |
Hex. Flange Elastic Nut M6 |
| 3560 |
517303756 |
Grommet |
| 3600 |
705017564 |
Lateral Cover This part replaces 705010334. |
| 4030 |
250000807 |
Torx Truss Screw M6 X 25 |
| 4040 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000957. |
| 4100 |
705009513 |
LH Central Lateral Panel |
| 4200 |
705009514 |
RH Central Lateral Panel This part replaces 705009514. |
| 4210 |
250000722 |
Torx Screw M6 X 20 |
| 4220 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000957. |
| 4230 |
705016606 |
Insert This part replaces 705010872. |
| 4300 |
705010676 |
LH Rear Lateral Panel |
| 4400 |
705010677 |
Deep Black, RH Rear Lateral Panel |
| 4410 |
293150104 |
Pop Rivet 3/16" |
| 4420 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000957. |
| 4440 |
705003841 |
Support Plate |
| 4610 |
250000722 |
Torx Screw M6 X 20 |
