| Ref | Part Number | Description |
|---|
| 10a |
291002778 |
Module Stifner |
| 10b |
243163560 |
Plastite Hex. Screw M6.8 X 35 |
| 10c |
279000214 |
REAR PIVOT ASS'Y - Call your local BRP dealership |
| 10d |
250200022 |
Flat Washer M6.6 X 22 |
| 10e |
207362060 |
Hex. Screw M6 X 20, Scotch Grip |
| 10f |
291003463 |
LH CENTER FRONT CARPET - Call your local BRP dealership |
| 10g |
291003464 |
RH CENTER FRONT CARPET - Call your local BRP dealership |
| 10h |
291003465 |
LH CENTER REAR CARPET - Call your local BRP dealership |
| 10j |
291003466 |
RH CENTER REAR CARPET - Call your local BRP dealership |
| 10k |
291002775 |
ANTI SLIP MAT REAR L - Call your local BRP dealership |
| 10m |
291002776 |
ANTI SLIP MAT REAR R - Call your local BRP dealership |
| 20a |
291002818 |
DECK NOSE - Call your local BRP dealership |
| 20b |
234042600 |
Flat Washer 4 mm, Stainless |
| 20c |
241142560 |
Hex. Flange Screw K40 X 25 |
| 30 |
291002607 |
ANTI SLIP MAT FL - Call your local BRP dealership |
| 35 |
291002608 |
RH Front Carpet |
| 60 |
293250200 |
NEOPRENE SEAL - Call your local BRP dealership |
| 65 |
293830005 |
Rubber Bumper |
| 69 |
219704381 |
SEAL 1000MM LONG - Call your local BRP dealership |
| 70 |
291004595 |
Front Module |
| 75 |
291004210 |
SEAT PIVOT - Call your local BRP dealership |
| 76 |
293150186 |
Pop Rivet 3/16 |
| 80 |
243163560 |
Plastite Hex. Screw M6.8 X 35 |
| 90 |
234082600 |
Flat Washer 8 mm, Stainless |
| 100 |
207361660 |
Hex. Screw M6 X 16, Scotch Grip |
| 110 |
291003306 |
LOWER CENTRAL REINFORCEMENT - Call your local BRP dealership |
| 120 |
291003416 |
UPPER REINFORCEMENT - Call your local BRP dealership |
| 130 |
207162560 |
Hex. Screw M6 X 25 |
| 140 |
234062600 |
Flat Washer M6, Stainless |
| 150 |
232561200 |
Brass Elastic Stop Nut M6 |
| 310 |
293150016 |
Rivet 1/8" |
| 320 |
293000014 |
Black, Snap Cap |
| 470a |
291004621 |
Black, Rear Handle |
| 470b |
291003878 |
Seat Stud |
| 470c |
232100600 |
Hex. Jam Nut M10 |
| 470d |
234002600 |
Flat Washer 10 mm, Stainless |
| 470e |
271001732 |
Elastic Nut M10 Housing |
| 480 |
207063060 |
Hex. Screw M6 X 30 |
| 490 |
234062600 |
Flat Washer M6, Stainless |
| 500 |
232561200 |
Brass Elastic Stop Nut M6 |
| 510 |
207363560 |
Screw Hex. M6 X 35, Scotch Grip |
| 520 |
250200022 |
Flat Washer M6.6 X 22 |
| 810 |
269501797 |
FRONT GRID - Call your local BRP dealership |
| 835 |
211000106 |
HEX. FORMING SCREW M6 X 16 - Call your local BRP dealership |
| 850 |
293150123 |
Pop Rivet 3/16" |
| 950 |
291004642 |
LH COSMETIC - Call your local BRP dealership This part replaces 291004256. |
| 960 |
291004258 |
RH Cosmetic |
| 970 |
293150123 |
Pop Rivet 3/16" |
| 1030 |
291004275 |
Front Bumper |
| 1050 |
250000399 |
Hexagonal Cap Screw M6 X35 |
| 1060 |
291004274 |
Rear Bumper |
| 1080 |
250000399 |
Hexagonal Cap Screw M6 X35 |
| 1090 |
291004451 |
Black, Side Bumper |
| 1110 |
250000399 |
Hexagonal Cap Screw M6 X35 |
| 1160 |
291002744 |
Bumber Cap |
| 1200 |
291002739 |
LH LATERAL REAR TRIM - Call your local BRP dealership |
| 1210 |
291002740 |
LH Rear Side Grille |
| 1240 |
291002741 |
RH Lateral Rear Trim |
| 1250 |
291002742 |
RH Rear Side Grille |
| 1260 |
219704476 |
Gasket, Neoprene 2000Mm Long This part replaces 219704372. |
| 1400 |
219704353 |
Was 271000110 Protection Trim |
| 2100c |
293250185 |
Lip Seal |
| 2100e |
293250209 |
LIP SEAL - Call your local BRP dealership |
| 2105c |
219704376 |
LIP SEAL 2000MM LONG - Call your local BRP dealership |
| 2105d |
219903090 |
WARNING DECAL, GASOLINE VAPOR - Call your local BRP dealership |
| 2105e |
219903084 |
CAUTION DECAL, ENGINE OIL - Call your local BRP dealership |
| 2110 |
205463560 |
Socket Head Screw M6 X 35 |
| 2112 |
250100150 |
Expansion Nut M6 X 1 |
| 2115 |
234062600 |
Flat Washer M6, Stainless |
| 2120 |
291002658 |
LH Rear Grille |
| 2125 |
291002698 |
RH REAR GRILL - Call your local BRP dealership |
| 2130 |
205463560 |
Socket Head Screw M6 X 35 |
| 2132 |
250100150 |
Expansion Nut M6 X 1 |
| 2134 |
234062600 |
Flat Washer M6, Stainless |
| 2136 |
250000681 |
Hex Screw M6 X 30 |
| 2138 |
234062600 |
Flat Washer M6, Stainless |
| 2140 |
291002837 |
LH Front Scraper Joint |
| 2150 |
291002838 |
RH FRONT SCRAPER JOINT - Call your local BRP dealership |
| 2160 |
291003818 |
MID JOINT - Call your local BRP dealership |
| 2170 |
293730010 |
Black Dart |
| 2180 |
291002696 |
LH REAR SCRAPER JOINT - Call your local BRP dealership |
| 2190 |
291002697 |
RH REAR SCRAPER JOINT - Call your local BRP dealership |
| 2192 |
293730006 |
Black, Dart |
| 2195 |
293150186 |
Pop Rivet 3/16 |
| 2200 |
291002694 |
LH FOOTREST COVER - Call your local BRP dealership |
| 2210 |
291002695 |
RH FOOTREST COVER - Call your local BRP dealership |
| 2240 |
293250231 |
GASKET - Call your local BRP dealership |
| 2250 |
291004280 |
Deflector |
| 2260 |
293150123 |
Pop Rivet 3/16" |
| 3000 |
572051500 |
Cap |
