| Ref | Part Number | Description |
|---|
| 1 |
0313173 |
SEAL, Motor cover |
| 2 |
0311020 |
SCREW, Clamp |
| 3 |
0305376 |
COVER, Silencer |
| 4 |
0305375 |
PAD, Silencer |
| 5 |
0305377 |
PLATE, Silencer |
| 6 |
0379638 |
SHORTENING SWITCH ASSY |
| 9 |
0304019 |
CROMMET, CONTROL SHAFT |
| 10 |
0382628 |
LOWER MOTOR COVER ASSEMBLY |
| 11 |
0309524 |
RETAINER, Shorting switch |
| 12 |
0307113 |
SCREW, Hook to cover |
| 13 |
0307290 |
HOOK, Cover to housing |
| 15 |
0306656 |
PLUG, Cover rear |
| 16 |
0553770 |
SEAL, Lower cover, small |
| 17 |
0306222 |
GROMMET |
| 18 |
0553784 |
SEAL, Lower cover, lalrge |
| 20 |
0306799 |
L'WASHER,Bracket to hsg. |
| 21 |
0309066 |
BRACKET, Lower cover |
| 22 |
0307468 |
SCREW, Mount bracket, starboard |
| 24 |
0379061 |
MOUNT, Lower cover |
| 25 |
0300646 |
VIS, ancrage |
| 26 |
0313779 |
NUT, Shorting switch |
| 27 |
0310441 |
CLAMP, CPS lead |
| 27 |
0330151 |
CLAMP, Harness to oil tank boss This part replaces 0309041. |
| 28 |
0554201 |
GROMMET, Cable to cover |
| 30 |
0330112 |
BRIDE, solénoïde vers démarreur This part replaces 0311218. |
| 33 |
0311217 |
MANCHON, solénoïde |
| 36 |
0552062 |
SCREW, Clamp |
| 37 |
0325972 |
COLLIER, câbles électriques This part replaces 0313786. |
