| Ref | Part Number | Description |
|---|
| 1 |
0912068 |
HOSE, Oil cooler to filter |
| 7 |
HOSE, |
Oil cooler to block, 39 in. |
| 8 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 10 |
0331215 |
HORSE, Elbow to tee This part replaces 0321890. |
| 12 |
0915209 |
O-RING, Aspirator |
| 13 |
0914903 |
ASPIRATOR |
| 15 |
0912064 |
SLEEVE, Oil cooler |
| 16 |
0912000 |
ELBOW, Oil cooler |
| 21 |
0985536 |
TUBE ASSY., Engine cover to coil cooler, return |
| 22 |
0985523 |
HOSE ASSEMBLY, Return |
| 23 |
0985524 |
HOSE ASSEMBLY, Pressure |
| 24 |
0912226 |
GROMMET, Return tube |
| 26 |
0325115 |
SCREW, Oil tank/EMM mount |
| 31 |
HOSE, |
Oil cooler to aspirator, 17 in. long |
| 32 |
0912204 |
PLATE, Oil cooler to block |
| 34 |
0329894 |
SCREW |
| 37 |
0317936 |
WASHER |
| 38 |
0913438 |
HOSE, 30 (DEGREE) Tee to check valve |
| 39 |
0122220 |
SEAL |
| 40 |
0913439 |
HOSE, Aspirator |
