| Ref | Part Number | Description |
|---|
| 1 |
0434161 |
ENGINE COVER ASSY., 300 |
| 1 |
0434162 |
ENGINE COVER ASSY., 300 |
| 1 |
0434163 |
ENGINE COVER ASSY., 300 |
| 1 |
0434626 |
ENGINE COVER ASSY., 250 |
| 1 |
0434627 |
ENGINE COVER ASSY., 250 |
| 2 |
0394976 |
LOCATING BRACKET, Rear |
| 3 |
0329762 |
LOCATING BRACKET, Front |
| 9 |
0397630 |
HOOK |
| 10 |
0336365 |
BAFFLE, Air intake |
| 11 |
0332320 |
SCREW, Anode |
| 12 |
0341495 |
SOUND BLANKET, Port This part replaces 0331632. |
| 12 |
0341498 |
SOUND BLANKET, Port, 300 This part replaces 0334871. |
| 13 |
0328009 |
TILT HANDLE |
| 14 |
0912173 |
SEAL, Engine cover |
| 15 |
0341500 |
SOUND BLANKET, Stbd. This part replaces 0331938. |
| 15 |
0341540 |
SOUND BLANKET, Stbd., 300 This part replaces 0334870. |
| 16 |
0336176 |
APPLIQUE, Counter rotating |
| 16 |
0336363 |
APPLIQUE, Power steering |
| 17 |
0330012 |
BAFFLE |
| 19 |
0331633 |
SOUND BLANKET, Front |
| 20 |
0341499 |
SOUND BLANKET, Top This part replaces 0336488. |
| 21 |
0334004 |
SCREW, Hook to bracket |
| 23 |
0330090 |
LOUVER, Engine cover, port |
| 23 |
0334782 |
LOUVER, Engine cover, stbd |
| 24 |
0330091 |
LOUVER, Engine cover, port |
| 24 |
0334781 |
LOUVER, Engine cover, port |
| 25 |
0332607 |
LIFT HANDLE |
| 25 |
0332608 |
LIFT HANDLE |
| 25 |
0913073 |
LIFT HANDLE |
| 26 |
0328608 |
BRACKET, Louver mounting., 300 |
| 0434350 |
0434350 |
OWNER'S MANUAL |
| 0434351 |
0434351 |
PAMPLET, Counter rotation |
| 0435243 |
0435243 |
DECAL SET, 250 |
| 0435244 |
0435658 |
DECAL SET This part replaces 0435244. |
