10- Electrical Harness Starter Harness_43M1514b
Parts (16)
| Ref | Part Number | Description |
|---|---|---|
| CF | 515175232 | Male Terminal |
| CF | 515175283 | Housing Support |
| CF | 515175817 | Male Terminal Housing, 8 Circuits |
| FA | 409004000 | Fuse Holder |
| FA | 409004200 | Female Terminal |
| FA | 410917200 | Fuse, 30 Amperes |
| FA | 710000992 | Clip |
| FB | 278000344 | Fuse, 5 Amperes |
| FB | 409011600 | Female Terminal |
| RY2 | 293750002 | Tie Wrap 142 mm |
| RY2 | 409209900 | Female Housing, 5 Circuits |
| RY2 | 561503100 | FEMALE TERMINAL - Call your local BRP dealership |
| RY2 | 710010053 | Relay This part replaces 515177041. |
| SD | 515177192 | Female Housing, 2 Circuits |
| SD | 710000925 | Terminal |
| SD | 710001332 | Seal Wire |
