CARBURETOR -- 15 HP
Parts (14)
| Ref | Part Number | Description |
|---|---|---|
| 10 | 0437287 | COVER, Carb. body |
| 22 | 0336842 | CLIP, SPRING |
| 36 | 0320107 | ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 37 | 0328388 | HOSE, Indicator |
| 39 | 0337415 | NUT |
| 40 | 0337353 | SCREW, Retainer & screen |
| 41 | 0337356 | SCREW, Air horn to carb., side |
| 42 | 0337357 | SCREW, Air horn to carb., top |
| 44 | 0318932 | JOINT |
| 45 | 0338914 | AIR HORN |
| 46 | 0341402 | RETAINER, Screen to air horn |
| 47 | 0340009 | SCREEN, Air horn |
| 5000283 | 5000283 | CARBURETOR ASSY. |
| 5000284 | 5000284 | CARBURETOR ASSY. |
