CHROME PUMP KITS 9.9 -15 HP
Parts (22)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 0318995 | PLATE, Impeller housing This part replaces 0319988. |
| 1 | 0662-560 | Engine (120) |
| 2 | 0608-807 | Throttle Lever Bracket |
| 3 | 2670-119 | Spacer M6 |
| 4 | 2670-134 | Throttle Lever Return Spring |
| 5 | 2670-194 | Throttle Cable Lever |
| 6 | 8050-222 | Flat Washer 1/4 X .734 X .063 |
| 7 | 8047-366 | Elastic Stop Nut 1/4-20 |
| 8 | 2670-193 | Governor Arm Spring |
| 9 | 8408-816 | Screw M8 X 1.25 X 16 |
| 10 | 1623-901 | Screw #10-32 X 1.50 |
| 11 | 2670-133 | Throttle Stop Adjuster Spring |
| 12 | 0610-821 | Breather Hose 7.5" |
| 13 | 2670-127 | Governor Arm Spring Return |
| 14 | 4606-770 | Resonator Retaining Bracket |
| 15 | 1623-984 | Wire Clamp 76.14MM LG W/6.25 HOL |
| 16 | 8020-134 | Cap Screw 5/16-18 |
| 17 | 8047-426 | Elastic Stop Nut 1/4-20 |
| 18 | 2623-277 | Blanking Plug 1.25" |
| 19 | 1623-550 | Screw 5/16-24 X .75 |
| 20 | 8050-247 | Flat Washer |
| 0389114 | 0394711 | CHROME PUMP KIT This part replaces 0389114. |
