| Ref | Part Number | Description |
|---|
| BAT2 |
710002576 |
Heat Shrink |
| BAT2 |
710003518 |
Terminal 45° |
| BD |
710002001 |
Housing Connector |
| BD |
710003047 |
Terminal |
| BN1 |
710000913 |
Terminal |
| BN1 |
710002589 |
Heat Shrink |
| BN2 |
278001392 |
Open Barrel Terminal |
| BN2 |
710002589 |
Heat Shrink |
| BN3 |
710000518 |
Open Barrel |
| BN3 |
710002577 |
Heat Shrink |
| BN4 |
710000507 |
Flat Open Baril |
| BN4 |
710002577 |
Heat Shrink |
| BP1 |
710000913 |
Terminal |
| BP1 |
710002589 |
Heat Shrink |
| BPR |
710000913 |
Terminal |
| BPR |
710002589 |
Heat Shrink |
| CC |
710000848 |
Lock |
| CC |
710000849 |
Male Housing, 6 Circuits |
| CC |
710001635 |
Terminal |
| CI |
515175801 |
Female Housing, 24 Circuits |
| CI |
515175802 |
Retainer Block |
| CI |
515175803 |
Wire Seal |
| CI |
515175812 |
Plug |
| CI |
710000399 |
Female Housing |
| CI |
710001131 |
Female Terminal |
| D2 |
409012700 |
Diode |
| D2 |
710002589 |
Heat Shrink |
| D4 |
409012700 |
Diode |
| D4 |
710002589 |
Heat Shrink |
| D5 |
409012700 |
Diode |
| D5 |
710002589 |
Heat Shrink |
| DB |
710002705 |
Lock |
| DB |
710002706 |
Female Housing 6 Circuits |
| DB |
710005438 |
Female Terminal |
| DB |
710005439 |
Female Terminal |
| DB2 |
710002704 |
Heat Shrink |
| DB2 |
710005439 |
Female Terminal |
| DC1 |
409010800 |
Female Terminal |
| DC2 |
409010800 |
Female Terminal |
| DC3 |
515175231 |
Female Terminal |
| DC3 |
515175658 |
Female Housing, 2 Circuits |
| DC3 |
710000667 |
Male Housing, 2 Circuits |
| DC4 |
515175231 |
Female Terminal |
| DC4 |
515175658 |
Female Housing, 2 Circuits |
| DC4 |
710000667 |
Male Housing, 2 Circuits |
| DC6 |
278000216 |
Wire Seal |
| DC6 |
278000217 |
Female Housing, 2 Circuits |
| DC6 |
278000218 |
Wire Seal |
| DC6 |
278000220 |
Male Connector, 2 Circuits |
| DC6 |
409007300 |
Female Terminal |
| DC6 |
710000992 |
Clip |
| DC7 |
278001007 |
Insulated Sheath |
| DC7 |
278001009 |
Female Terminal This part replaces 290964068. |
| DPS |
278002187 |
Female Terminal |
| DPS |
710001222 |
Lock |
| DPS |
710001858 |
Seal |
| DPS |
710001860 |
Seal |
| DPS |
710001873 |
Terminal This part replaces 710001765. |
| DPS |
710002075 |
Plug |
| DPS |
710004989 |
Female Housing |
| DPS |
710005098 |
Lock |
| DPS |
710005760 |
DPS Connector Cap |
| DPSSW |
710002000 |
Housing |
| DPSSW |
710003047 |
Terminal |
| ECM |
710001588 |
Female Terminal Housing, 48 Circuits |
| ECM |
710001589 |
Female Terminal |
| ECM |
710001591 |
Cover, 48 positions |
| ECM |
710001592 |
Plug |
| ECM |
710001593 |
Plug |
| ECM |
710001727 |
Female Terminal |
| ECM |
710002713 |
Tie-Rap, 100mm |
| FL1 |
710004228 |
Fuse Link |
| FL2 |
715002538 |
Fuse Link 41-50AMP This part replaces 710004227. |
| FL3 |
710004228 |
Fuse Link |
| FP |
278001013 |
Wire Seal |
| FP |
278001014 |
Female Terminal |
| FP |
409209700 |
Female Housing, 4 Circuits |
| FP |
515176621 |
Wire Seal |
| FP |
710001340 |
Female Terminal |
| FRA |
515175231 |
Female Terminal |
| FRA |
515175658 |
Female Housing, 2 Circuits |
| FT |
278000217 |
Female Housing, 2 Circuits |
| FT |
278000218 |
Wire Seal |
| FT |
409004300 |
Male Terminal |
| FT |
710000992 |
Clip |
| HIBM |
710002000 |
Housing |
| HIBM |
710003047 |
Terminal |
| HIBM |
710003048 |
Terminal |
| HIC |
710001222 |
Lock |
| HIC |
710001225 |
Cap |
| HIC |
710001228 |
Terminal |
| HIC |
710001229 |
Terminal |
| HIC |
710001230 |
Seal |
| HIC |
710001233 |
Seal |
| HIC |
710001928 |
Housing |
| HIC5 |
278000222 |
Male Terminal |
| HIC5 |
278000394 |
FEMALE HOUSING, 4 CIRCUITS - Call your local BRP dealership |
| HIC5 |
278001065 |
Wire Seal This part replaces 278000585. |
| HIC5 |
710000992 |
Clip |
| HIC7 |
278000217 |
Female Housing, 2 Circuits |
| HIC7 |
278000218 |
Wire Seal |
| HIC7 |
409004300 |
Male Terminal |
| HIC7 |
710000992 |
Clip |
| HIC8 |
710003175 |
Housing |
| HIC8 |
710003177 |
Housing |
| HO2S1 |
278001482 |
Seal |
| HO2S1 |
710002466 |
Housing |
| HO2S1 |
710002469 |
Lock |
| HO2S1 |
710002597 |
Gold Terminal |
| HO2S2 |
278001482 |
Seal |
| HO2S2 |
710002466 |
Housing |
| HO2S2 |
710002469 |
Lock |
| HO2S2 |
710002597 |
Gold Terminal |
| OVR |
710002000 |
Housing |
| OVR |
710003047 |
Terminal |
| PDH |
710000918 |
Female Terminal |
| PDH |
710001427 |
Wire Seal |
| PDH |
710002278 |
Housing |
| PDH |
710002279 |
Lock |
| PDL |
710000918 |
Female Terminal |
| PDL |
710001427 |
Wire Seal |
| PDL |
710002278 |
Housing |
| PDL |
710002279 |
Lock |
| PF1 |
278000999 |
Wire Seal |
| PF1 |
278002172 |
Foam |
| PF1 |
415128501 |
Seal |
| PF1 |
415129856 |
Fuse Box Base Ass´y This part replaces 710000660. |
| PF1 |
515176774 |
Relay, 30 AMP |
| PF1 |
710000742 |
Little Fuse, 5 Amperes |
| PF1 |
710000743 |
Little Fuse, 7.5 Amperes |
| PF1 |
710000744 |
Little Fuse, 10 Amperes |
| PF1 |
710000745 |
Little Fuse, 15 Ampere |
| PF1 |
710000747 |
Little Fuse, 30 Amperes |
| PF1 |
710000781 |
Fuse Puller |
| PF1 |
710000836 |
Female Terminal |
| PF1 |
710000837 |
Female Terminal |
| PF1 |
710000840 |
Cap |
| PF1 |
710001026 |
Fuse Cover |
| PF1 |
710002590 |
Fuse, 25 Amps |
| PF1 |
710002715 |
Logo Fuse Relay |
| PF1 |
715900824 |
Relay This part replaces 710001778. |
| PF3 |
278000805 |
Cushion |
| PF3 |
278001325 |
Fuse Holder |
| PF3 |
278001326 |
Fuse Holder Cap |
| PF3 |
710000357 |
Female Terminal |
| PF3 |
710001613 |
Fuse |
| PGH |
710000918 |
Female Terminal |
| PGH |
710001427 |
Wire Seal |
| PGH |
710002278 |
Housing |
| PGH |
710002279 |
Lock |
| PGL |
710000918 |
Female Terminal |
| PGL |
710001427 |
Wire Seal |
| PGL |
710002278 |
Housing |
| PGL |
710002279 |
Lock |
| PPS |
278002299 |
Female Terminal Housing 6 Circuits |
| PPS |
710001119 |
Female Terminal |
| RD1 |
710000879 |
Female Housing, 3 Circuits This part replaces 278003517. |
| RD1 |
710001932 |
Seal |
| RD1 |
710001934 |
Terminal |
| RD1 |
710005830 |
Lock |
| SB |
278001482 |
Seal |
| SB |
710001134 |
Female Terminal |
| SB |
710002043 |
Lock |
| SB |
710002177 |
Housing |
| SPSW |
710002000 |
Housing |
| SPSW |
710003047 |
Terminal |
| SS |
515177192 |
Female Housing, 2 Circuits |
| SS |
710000925 |
Terminal |
| SS |
710001163 |
Wire Seal |
| STSW |
409012100 |
Female Terminal |
| STSW |
409209200 |
Female Terminal Housing, 2 Circuits |
| STSW |
710000402 |
Wire Seal |
| SW1 |
409010300 |
Female Terminal |
| SW2 |
409010300 |
Female Terminal |
| SW3 |
710000038 |
Female Terminal |
| SW4 |
278000992 |
Open Barrel |
| SW4 |
710002588 |
Heat Shrink Tubing |
| SWW |
710002003 |
Housing Connector |
| SWW |
710003047 |
Terminal |
| SWWRC |
278000273 |
Male Housing, 3 Circuits |
| SWWRC |
278001065 |
Wire Seal This part replaces 278000585. |
