| Ref | Part Number | Description |
|---|
| 3 |
0303791 |
SCREW |
| 6 |
0330151 |
CLAMP, Harness to oil tank boss This part replaces 0309041. |
| 7 |
0317753 |
SCREW |
| 9 |
0909024 |
CLAMP, Retainer |
| 10 |
3852499 |
RETAINER, Fuse This part replaces 0910330. |
| 11 |
0981890 |
LEAAD ASSY |
| 13 |
0912210 |
CLAMP |
| 14 |
0912305 |
COVER, Solenoid terminal stud |
| 15 |
0984056 |
CABLE ASSY, Solenoid to motor |
| 16 |
3852527 |
RING TERMINAL This part replaces 0911523. |
| 20 |
0912595 |
CLAMP, Trim & tilt connector |
| 21 |
0912852 |
BRACKET, Ignition leads, stbd. |
| 22 |
0985704 |
CABLE ASSY, Trim/tilt |
| 26 |
0985063 |
SOLENOID |
| 27 |
0984853 |
BRACKET & SPACER |
| 28 |
0307708 |
RONDELLE GROWER |
| 29 |
0984935 |
FUSE HOLDER & LEAD, 19" (483mm) long |
| 29 |
0984937 |
FUSE HOLDER & LEAD, 22" (559mm) long |
| 32 |
3852527 |
RING TERMINAL This part replaces 0911523. |
| 33 |
0317753 |
SCREW |
| 34 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 35 |
0984936 |
CABLE ASSY., Engine |
| 37 |
3852527 |
RING TERMINAL This part replaces 0911523. |
| 45 |
3852619 |
RETAINER This part replaces 0912850. |
| 46 |
0309484 |
SCREW |
| 47 |
0984911 |
CONNECTOR & LEAD, Engine alarm |
| 48 |
0123405 |
CONNECTOR |
