| Ref | Part Number | Description |
|---|
| 8 |
0360252 |
WASHER This part replaces 0306311. |
| 10 |
506153236 |
Handle Bar |
| 20 |
506153352 |
Grip This part replaces 506153175. |
| 22 |
0324677 |
JOINT TORIQUE, mamelon, vidange inférieure |
| 23 |
0324678 |
JOINT TORIQUE Galet de came de papillon |
| 25 |
506153403 |
Heating Element 28W This part replaces 506153135. |
| 30 |
3852508 |
O-RING, Reservoir This part replaces 0910702. |
| 31 |
0910866 |
HOUSING, Valve seat |
| 33 |
0911307 |
WASHER |
| 34 |
0911603 |
VALVE SEAT, Filter |
| 35 |
0911620 |
SEAT, Relief valve |
| 36 |
0911965 |
SPRING, Pump relief |
| 37 |
0911966 |
SPRING, Relief valve |
| 38 |
0800128 |
BALL |
| 39 |
0912297 |
PLUG |
| 40 |
0912299 |
SCREW, Short |
| 41 |
0912300 |
SCREW, Long |
| 42 |
0983786 |
VALVE CORE & SEAL |
| 43 |
0984032 |
OIL PUMP ASSY. |
| 44 |
0984356 |
MOTOR & CABLE ASSY. |
| 46 |
0984961 |
SEAL & BRUSH KIT |
| 47 |
0984357 |
COVER & DECAL ASSY. |
| 48 |
3853825 |
OIL LINE ASSY., Pump to manifold This part replaces 0984645. |
| 50 |
506153177 |
Thermal Insulation |
| 52 |
0912261 |
APPLIQUE, Tilt cylinder |
| 53 |
0913812 |
PIVOT PIN, Tilt cylinder This part replaces 0912810. |
| 54 |
3853329 |
LOCKNUT, Transom plate This part replaces 0912920. |
| 55 |
3852568 |
SCREW, Cover This part replaces 0911859. |
| 56 |
3852378 |
COVER, Tilt cylinder This part replaces 0911907. |
| 57 |
0912811 |
SPACER, Drive unit |
| 58 |
3852573 |
WASHER, Pivot pin This part replaces 0911915. |
| 59 |
3852579 |
RETAINER, Oil line This part replaces 0911967. |
| 60 |
3852681 |
RETAINER, Cover This part replaces 0913245. |
| 61 |
0910855 |
BUSHING, Pivot pin |
| 62 |
3853854 |
OIL LINE, Starboard, down This part replaces 0985614. |
| 62 |
3853856 |
OIL LINE, Port, down This part replaces 0985616. |
| 63 |
3853855 |
OIL LINE, Starboard, up This part replaces 0985615. |
| 63 |
3853857 |
OIL LINE, Port, up This part replaces 0985617. |
| 64 |
0985660 |
CYLINDER ASSY |
| 65 |
0985060 |
SEAL KIT |
| 66 |
3854248 |
SPACER, Tilt limit This part replaces 0913361. |
| 67 |
0329241 |
RONDELLE |
| 68 |
0985394 |
GROUND WIRE, 2-loop |
| 71 |
3852581 |
LAG SCREW This part replaces 0911975. |
| 72 |
3853848 |
GROUND WIRE, 3-loop This part replaces 0985392. |
| 400 |
860201427 |
Riser Kit 120 |
| 405 |
506152867 |
LH Handlebar Support |
| 406 |
506152928 |
RH Handlebar Support |
| 410 |
506152894 |
Steering Support |
| 420 |
250000904 |
Button Head Torx Screw M8 X 38 |
| 430 |
250000852 |
Hexagonal Flange Screw M8 X 1.25 x 60 |
| 520 |
506153144 |
Moulding Strap Ass'y |
| 540 |
250000779 |
Torx Screw M6 X 1.0 X 18, Scotch Grip |
| 900a |
506153197 |
LH Swivel Arm Ass'y |
| 900a2 |
503194671 |
Bushing |
| 900b |
506152790 |
RH Swivel Arm |
| 900b2 |
503194671 |
Bushing |
| 900c |
506152792 |
Pivot Arm |
| 900d |
503191800 |
Washer |
| 900f |
506153198 |
Steering Support |
| 900g1 |
250300038 |
Clinch Stud |
| 900h |
207088544 |
HEX. SCREW M8 X 85 - Call your local BRP dealership |
| 900j |
503192494 |
Washer |
| 900k |
233281466 |
Elastic Flang Nut M8 |
| 900m |
506152755 |
Ball Joint |
| 900n |
250001028 |
Hex. Flanged Screw M6 X 45 |
| 900p |
506151245 |
Washer |
| 900q |
233281466 |
Elastic Flang Nut M8 |
| 903 |
506153157 |
Steering Stopper |
| 905 |
233281416 |
Hex. Elastic Flanged Nut M8 |
| 910 |
207662044 |
Hex. Flange Screw M6 X 20 |
| 915 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 920 |
207687044 |
Hex. Flange Screw M8 X 70 |
| 930 |
207685044 |
Hex. Flange Screw M8 X 50 |
| 940 |
506151245 |
Washer |
| 950 |
233281416 |
Hex. Elastic Flanged Nut M8 |
| 960 |
506152753 |
Ball Joint |
| 970 |
506152582 |
Washer |
| 980 |
232500416 |
Elastic Stop Nut M10 |
| 1000 |
506153026 |
Main Tube |
| 1010 |
506152219 |
Upper Half Housing |
| 1012 |
506153048 |
Lower Half Housing |
| 1014 |
506152292 |
Upper Vibration Ring |
| 1016 |
506152518 |
Lower Vibration Ring |
| 1020 |
506153249 |
Housing Bushing |
| 1021 |
250001114 |
Hex Flange Screw M6 x 75 |
| 1022 |
233261416 |
Elastic Flanged Nut M6 X 1.0 |
| 1030 |
506153249 |
Housing Bushing |
| 1031 |
250001114 |
Hex Flange Screw M6 x 75 |
| 1032 |
233261416 |
Elastic Flanged Nut M6 X 1.0 |
| 1040 |
506153249 |
Housing Bushing |
| 1050 |
506153248 |
Housing Bushing |
| 1051 |
207687044 |
Hex. Flange Screw M8 X 70 |
| 1052 |
233281416 |
Hex. Elastic Flanged Nut M8 |
| 1053 |
506152938 |
Stopper Plate |
| 1100 |
506153294 |
Cap |
| 1110 |
293150008 |
Pop Rivet 3/16" |
| 1250 |
506153056 |
Rod Ass'y |
| 1280 |
506152582 |
Washer |
| 0984355 |
0984355 |
MANIFOLD & PUMP ASSY. |
