| Ref | Part Number | Description |
|---|
| 1 |
0434110 |
ENGINE COVER ASSY., 200TX |
| 1 |
0434111 |
ENGINE COVER ASSY., 200CX |
| 1 |
0434112 |
ENGINE COVER ASSY., 225 |
| 1 |
0434114 |
ENGINE COVER ASSY., 225 |
| 1 |
0434115 |
ENGINE COVER ASSY., 225 |
| 2 |
0331945 |
BAFFLE |
| 3 |
0331944 |
TILT HANDLE |
| 5 |
0329762 |
LOCATING BRACKET, Front |
| 6 |
0394976 |
LOCATING BRACKET, Rear |
| 8 |
0334947 |
SOUND BLANKET, Side |
| 9 |
0334911 |
BAFFLE |
| 13 |
0336363 |
APPLIQUE, Power steering |
| 15 |
0336176 |
APPLIQUE, Counter rotating |
| 18 |
0336188 |
NUT, Baffle |
| 20 |
0334948 |
SOUND BLANKET, Front |
| 21 |
0334949 |
SOUND BLANKET, Rear |
| 22 |
0334967 |
SCREW, Baffle |
| 24 |
0334910 |
LOUVER, Engine cover, stbd |
| 25 |
0334909 |
LOUVER, Engine cover, port |
| 26 |
0435215 |
DECAL SET, 200TX, 200CX |
| 26 |
0435217 |
DECAL SET, 225 |
| 27 |
0434343 |
OWNER'S MANUAL |
