| Ref | Part Number | Description |
|---|
| 33 |
278000999 |
Wire Seal This part replaces 710000838. |
| 44 |
515175231 |
Female Terminal |
| 54 |
515175495 |
Female Housing, 3 Circuits |
| 61 |
409012900 |
Male Terminal |
| 62 |
278001014 |
Female Terminal |
| 66 |
710000779 |
Housing |
| 70 |
409209700 |
Female Housing, 4 Circuits |
| 73 |
278001013 |
Wire Seal |
| 75 |
409010700 |
Female Terminal |
| 77 |
409010300 |
Female Terminal |
| 79 |
710000038 |
Female Terminal |
| 80 |
278000230 |
Male Terminal |
| 99 |
278000992 |
Open Barrel |
| 110 |
278000631 |
Male Terminal |
| 112 |
278000632 |
Female Terminal |
| 127 |
409207600 |
Male Lock, 3 Circuits |
| 138 |
293000052 |
Sealing Cap |
| 196 |
293750002 |
Tie Wrap 142 mm |
| 227 |
409004300 |
Male Terminal |
| 229 |
278000223 |
Female Terminal |
| 231 |
278000217 |
Female Housing, 2 Circuits |
| 232 |
278000281 |
Female Terminal Housing, 3 Circuits |
| 238 |
278000273 |
Male Housing, 3 Circuits |
| 242 |
278000218 |
Wire Seal |
| 244 |
278000216 |
Wire Seal |
| 253 |
219704425 |
Tubing 6 Mm 3000Mm Long |
| 254 |
219704399 |
Was 409901700 Tubing (9 mm) |
| 255 |
219704400 |
Was 409901800 Tubing (13 mm) |
| 256 |
219704408 |
Tubing 16 Mm 1000Mm Long |
| 257 |
219704398 |
Was 409901600 Tubing 19mm |
| 279 |
409011300 |
Male Terminal |
| 280 |
409012100 |
Female Terminal |
| 284 |
409012300 |
Seal |
| 287 |
710000080 |
Cap |
| 295 |
278001008 |
Insulated Sheath |
| 297 |
278001007 |
Insulated Sheath |
| 318 |
278001477 |
FEMALE HOUSING, 4 CIRCUITS - Call your local BRP dealership |
| 319 |
515175588 |
FEMALE TERMINAL HOUSING, 2 CIRCUITS - Call your local BRP dealership |
| 334 |
710000081 |
Female Housing, 6 Circuits |
| 346 |
278001478 |
MALE WEDGE, 4 CIRCUITS - Call your local BRP dealership |
| 355 |
515175658 |
Female Housing, 2 Circuits |
| 359 |
515175666 |
Male Housing |
| 365 |
515175672 |
CONNECTOR_MALE 4 CAVITIES - Call your local BRP dealership |
| 366 |
515175673 |
Male Housing, 6 Circuits |
| 370 |
515175677 |
MALE WEDGE, 4 CIRCUITS - Call your local BRP dealership |
| 371 |
515175678 |
Male Wedge, 6 Circuits |
| 387 |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| 388 |
278001750 |
FEMALE TERMINAL - Call your local BRP dealership |
| 391 |
278001751 |
MALE HOUSING, 41 CIRCUITS - Call your local BRP dealership |
| 401 |
278001505 |
WIRE SEAL - Call your local BRP dealership |
| 409 |
515175812 |
Plug |
| 410 |
515175801 |
Female Housing, 24 Circuits |
| 411 |
515175802 |
Retainer Block |
| 412 |
515175803 |
Wire Seal |
| 415 |
515175806 |
Female Terminal |
| 437 |
515175886 |
SEAL - Call your local BRP dealership |
| 438 |
515175883 |
Latch |
| 439 |
515175884 |
LOCK - Call your local BRP dealership |
| 440 |
515175885 |
COVER - Call your local BRP dealership |
| 442 |
710000329 |
Male Housing, 4 Circuits |
| 443 |
710000335 |
Female Terminal |
| 464 |
710000274 |
Female Terminal |
| 478 |
710000888 |
Housing, 6 Circuits |
| 479 |
710000889 |
Lock |
| 498 |
710000399 |
Female Housing |
| 499 |
710000402 |
Wire Seal |
| 506 |
710000421 |
Female Terminal |
| 524 |
512059668 |
Heat Shrink Tubing 25 mm |
| 525 |
710000482 |
SHRINK TUBING - Call your local BRP dealership |
| 579 |
710000504 |
Wire Seal |
| 612 |
710000562 |
Female Housing |
| 663 |
515176774 |
Relay, 30 AMP This part replaces 710000739. |
| 664 |
515176775 |
Relay, 50 AMP This part replaces 710000740. |
| 666 |
710000742 |
Little Fuse, 5 Amperes |
| 667 |
710000743 |
Little Fuse, 7.5 Amperes |
| 669 |
710000745 |
Little Fuse, 15 Ampere |
| 670 |
710000746 |
Little Fuse, 20 Amperes |
| 671 |
710000747 |
Little Fuse, 30 Amperes |
| 672 |
710000748 |
Diode |
| 674 |
710001026 |
Fuse Cover This part replaces 710000659. |
| 675 |
415129856 |
Fuse Box Base Ass´y This part replaces 710000660. |
| 684 |
710000781 |
Fuse Puller |
| 685 |
710000782 |
FEMALE TERMINAL - Call your local BRP dealership |
| 690 |
710000890 |
Female Terminal |
| 700 |
710000835 |
Male Terminal Housing, 6 Circuits |
| 702 |
710000836 |
Female Terminal |
| 703 |
710000837 |
Female Terminal |
| 706 |
710000840 |
Cap |
| 709 |
710000848 |
Lock |
| 711 |
710000849 |
Male Housing, 6 Circuits |
| 714 |
710000855 |
DECAL, FUSE RELAY - Call your local BRP dealership |
| 732 |
710000877 |
Female Terminal |
| 734 |
710000879 |
Female Housing, 3 Circuits |
| 735 |
710000880 |
Housing, 3 Circuits |
| 736 |
710000881 |
Seal |
| 737 |
710000882 |
Cap |
| 738 |
710000897 |
Cover |
| 750 |
710000913 |
Terminal |
| 764 |
710000992 |
Clip |
| 800 |
278002187 |
Female Terminal |
